DSL-2740U Wireless ADSL2+ Router with Ethernet WAN Support
User Manual
Configuring via Web-based Interface
In the opened window, you can specify the following parameters:
Parameter Description
Enable rule
Move the switch to the right to enable the rule.
Move the switch to the left to disable the rule.
Action
Select an action for the rule.
Deny: Blocks access to the router's network for the device with the
specified MAC address.
Allow: Allows access to the router's network and to the Internet for
the device with the specified MAC address when the rules on the
Firewall / IP Filter page block access for this device.
MAC address
The MAC address of a device from the router's LAN. You can enter
the MAC address of a device connected to the router's LAN at the
moment. To do this, select the relevant device from the drop-down
list (the field will be filled in automatically).
After specifying the needed parameters, click the SAVE button.
To edit a rule, select the relevant line in the table. In the opened window, change the needed
parameters and click the SAVE button.
To remove a rule, select the checkbox located to the left of the relevant line of the table and click
the DELETE button. Also you can remove a rule in the editing window.
