D-Link DWA-121 User Manual

24D-Link DWA-121 User Manual
Section 3 - Conguration
Press the WPS button located on the right side of the Router/Access point until
it is lit and click on the virtual Connect Now button.

D-Link DWA-121 Specifications

Power

operating voltage	5 VDC +/- 5%
power consumption (transmit mode)	230 mA
power consumption (receive mode)	120 mA

Operating Environment

operating temperature	0 to 40 ºC (32 to 104 ˚F)
operating humidity	10% to 90% maximum (non-condensing)
frequency range	2.4GHz to 2.483GHz (North America)

Weight and Dimensions

dimensions	0.7” x .06” x 0.2”
weight	2.2 g
