D-Link DWA-121 User Manual

41D-Link DWA-121 User Manual
Section 4 - Wireless Security
Congure WPA/WPA2 Passphrase
Using the Windows
®
XP Utility
It is recommended to enable WPA-PSK on your wireless router or access point before conguring your wireless adapter. If you are joining an existing
network, you will need to know the WPA-PSK key being used.
2. Highlight the wireless network (SSID) you would like to connect to
and click Connect.
1. Open the Windows XP Wireless Utility by right-clicking on the wireless
computer icon in your system tray (lower-right corner of screen). Select
View Available Wireless Networks.

D-Link DWA-121 Specifications

Power

operating voltage	5 VDC +/- 5%
power consumption (transmit mode)	230 mA
power consumption (receive mode)	120 mA

Operating Environment

operating temperature	0 to 40 ºC (32 to 104 ˚F)
operating humidity	10% to 90% maximum (non-condensing)
frequency range	2.4GHz to 2.483GHz (North America)

Weight and Dimensions

dimensions	0.7” x .06” x 0.2”
weight	2.2 g
