D-Link DWA-121 User Manual

34D-Link DWA-121 User Manual
Section 4 - Wireless Security
Congure WPA/WPA2 Passphrase
Using the D-Link Wireless Connection Manager
It is recommended to enable WPA-PSK on your wireless router or access point before conguring your wireless adapter. If you are joining an existing
network, you will need to know the WPA-PSK passphrase being used.
1. Open the Wireless Connection Manager by double-clicking on the D-Link icon on your desktop.
2. Highlight the wireless network (SSID) you would like to connect to and click Connect. If the network is using WPA-PSK, the screen (as shown to
the bottom-right) will appear.
3. Enter the WPA-PSK passphrase exactly as it is on your wireless router or access
point. Click the Show text in the password eld box to see the passphrase.
Unchecking it will hide it.
4. Click OK to connect to the network. Allow up to 30 seconds to connect.
If you would like to create a new network and enter the WPA-PSK settings, refer to
the next page.

D-Link DWA-121 Specifications

Power

operating voltage	5 VDC +/- 5%
power consumption (transmit mode)	230 mA
power consumption (receive mode)	120 mA

Operating Environment

operating temperature	0 to 40 ºC (32 to 104 ˚F)
operating humidity	10% to 90% maximum (non-condensing)
frequency range	2.4GHz to 2.483GHz (North America)

Weight and Dimensions

dimensions	0.7” x .06” x 0.2”
weight	2.2 g
