D-Link DWA-121 User Manual

38D-Link DWA-121 User Manual
Section 4 - Wireless Security
5. Enter the same security key or passphrase that is on your router and click
Connect.YoucanalsoconnectbypushingtheWPSbuttonontherouter.
It may take 20-30 seconds to connect to the wireless network. If the connection
fails, please verify that the security settings are correct. The key or passphrase
must be exactly the same as on the wireless router.

D-Link DWA-121 Specifications

Power

operating voltage	5 VDC +/- 5%
power consumption (transmit mode)	230 mA
power consumption (receive mode)	120 mA

Operating Environment

operating temperature	0 to 40 ºC (32 to 104 ˚F)
operating humidity	10% to 90% maximum (non-condensing)
frequency range	2.4GHz to 2.483GHz (North America)

Weight and Dimensions

dimensions	0.7” x .06” x 0.2”
weight	2.2 g
