D-Link DWA-131 User Manual

16D-Link DWA-131 User Manual
Section 2 - Installation
Push Button Configuration (PBC)
To connect to your network using the WPS push button
configuration method, click the virtual button as shown in the
screenshot.
Note: You may also connect to your network by pressing the
WPS button on the adaper and holding for two seconds until the
wizard screen comes up. Then, press the WPS button on the
router/access point to continue.
Press the WPS button on your access point or wireless router
within 2 minutes to establish connectivity.
Select “Use the WiFi Proctected Setup (WPS)” to initiate the
configuration and click Next.

D-Link DWA-131 Specifications

Wireless Standards

standard	IEEE 802.11n, IEEE 802.11g

Interface

bus type	USB 2.0 (1.1 compatible)

Frequency and Modulation

frequency range	2.4GHz to 2.4835GHz
modulation technology	Orthogonal Frequency Division Multiplexing (OFDM), Complementary Code Keying (CCK)

Power and Operating Conditions

operating voltage	5 VDC +/- 10%
operating temperature	32°F to 104°F (0°C to 40°C)
operating humidity	10% to 90% maximum (non-condensing)

Weight and Dimensions

dimensions	1.1” x 3.4” x 0.5”
weight	0.06 lbs (27.22g)
