Appendix B - Networking Basics
Statically Assign an IP address
If you are not using a DHCP capable gateway/router, or you need to assign a static IP address, please follow the steps
below:
Windows
®
XP/2000 Users
• Windows
®
XP - Click on Start > Control Panel. Make sure you are in Classic View. Double-click on the Network Connections
icon.
Windows
®
2000 – From the desktop, right-click My Network Places > Properties.
• Right-click on the Local Area Connection which represents your D-Link wireless network adapter (or other adapter) which will
be connected to your router.
• Highlight Internet Protocol (TCP/IP) and click Properties.
• Click Use the following IP address and enter an IP address that is on the same subnet
as your network or LAN IP address on your router.
Example: If the router’s LAN IP address is 192.168.0.1, make your IP address 192.168.0.X
where X is a number between 2 and 99. Make sure that the number you choose is not
in use on the network.
• Set Default Gateway the same as the LAN IP address of your router or gateway.
• Set Primary DNS the same as the LAN IP address of your router or gateway.
• The Secondary DNS is optional (you may enter a DNS server from your ISP).
• Click OK to save your settings.

D-Link DWA-131 Specifications

Wireless Standards

standard	IEEE 802.11n, IEEE 802.11g

Interface

bus type	USB 2.0 (1.1 compatible)

Frequency and Modulation

frequency range	2.4GHz to 2.4835GHz
modulation technology	Orthogonal Frequency Division Multiplexing (OFDM), Complementary Code Keying (CCK)

Power and Operating Conditions

operating voltage	5 VDC +/- 10%
operating temperature	32°F to 104°F (0°C to 40°C)
operating humidity	10% to 90% maximum (non-condensing)

Weight and Dimensions

dimensions	1.1” x 3.4” x 0.5”
weight	0.06 lbs (27.22g)
