Section 4 - Wireless Security
Configure WPA/WPA2 (RADIUS)
Using the D-Link Wireless Connection Manager
WPA and WPA2 are for advanced users who are familiar with using a RADIUS server and setting up certificates.
1. Open the Wireless Connection Manager by double-clicking on the D-Link
icon on your desktop. Click on New to create a new profile or highlight an
existing profile and click Modify.
2. Select WPA/WPA2-Enterprise under Set Security Option and then select
TKIP or AES.
3. Click on Advanced Config to continue.
4. Next to EAP Type, select EAP-TLS, EAP-TTLS, or PEAP. Extensible
Authentication Protocols allow devices on the network to request
authentication from the RADIUS server in the network. All the devices
on the network must use the same EAP type when using a RADIUS
server for authentication. Some RADIUS servers require that the Validate
Server field be selected. Check this field if your RADIUS server requires
validation.
5. Select a User Certificate from the drop-down menu.
6. Enter the login information required to authenticate.
7. Click Add to enter the IP address(es) of your RADIUS servers.
8. Click OK to save your settings.

D-Link DWA-131 Specifications

Wireless Standards

standard	IEEE 802.11n, IEEE 802.11g

Interface

bus type	USB 2.0 (1.1 compatible)

Frequency and Modulation

frequency range	2.4GHz to 2.4835GHz
modulation technology	Orthogonal Frequency Division Multiplexing (OFDM), Complementary Code Keying (CCK)

Power and Operating Conditions

operating voltage	5 VDC +/- 10%
operating temperature	32°F to 104°F (0°C to 40°C)
operating humidity	10% to 90% maximum (non-condensing)

Weight and Dimensions

dimensions	1.1” x 3.4” x 0.5”
weight	0.06 lbs (27.22g)
