D-Link DWA-131 User Manual

33D-Link DWA-131 User Manual
Section 4 - Wireless Security
It is recommended to enable WPA-PSK on your wireless router or access point before configuring your wireless adapter.
Make sure you enter the passphrase exactly the same on all wireless devices.
1. Open the Wireless Connection Manager by double-clicking on the D-Link icon on your desktop. Click on New to
create a new profile or highlight an existing profile and click Modify.
2. Select WPA/WPA2-Personal under Set Security Option.
3. Select TKIP or AES.
4. Enter the passphrase exactly as it is on your wireless router
or access point.
5. Click OK to connect to the network. Allow up to 30 seconds
to connect.

D-Link DWA-131 Specifications

Wireless Standards

standard	IEEE 802.11n, IEEE 802.11g

Interface

bus type	USB 2.0 (1.1 compatible)

Frequency and Modulation

frequency range	2.4GHz to 2.4835GHz
modulation technology	Orthogonal Frequency Division Multiplexing (OFDM), Complementary Code Keying (CCK)

Power and Operating Conditions

operating voltage	5 VDC +/- 10%
operating temperature	32°F to 104°F (0°C to 40°C)
operating humidity	10% to 90% maximum (non-condensing)

Weight and Dimensions

dimensions	1.1” x 3.4” x 0.5”
weight	0.06 lbs (27.22g)
