D-Link DWA-510 User Manual

43D-Link DWA-510 User Manual
Section 4 - Wireless Security
3. The Wireless Network Connection box will appear. Enter the WPA/WPA2
passphrase and click Connect.
It may take 20-30 seconds to connect to the wireless network. If the connection
fails, please verify that the WPA-PSK settings are correct. The WPA-PSK
passphrase must be exactly the same as on the wireless router or access
point.

D-Link DWA-510 Specifications

General

Modulation	DBPSK
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2-PSK
Maximum data transfer rate	54 Mbit/s
Connectivity technology	Wireless
RX power consumption	260 mA
Gain	2 dBi
Link/Act LED	Yes
Dimensions (WxDxH)	126 x 12 x 19 mm
Compliance industry standards	IEEE 802.11g/b
Compatible operating systems	Windows 98SE, ME, 2000, XP, Vista
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Certification	FCC Class B, CE, C-Tick, IC, Wi-Fi, WPS
