D-Link DWA-510 User Manual

45D-Link DWA-510 User Manual
Section 4 - Wireless Security
Configure 802.1x
Using the D-Link Wireless Connection Manager
802.1x is for advanced users who are familiar with using a RADIUS server and setting up certificates.
1. OpentheWirelessUtilitybydouble-clickingontheD-Linkiconinyoursystemtray(lower-right
corner of screen). Click on New to create a new profile or highlight an existing profile and click
Modify.
2. Select 802.1x under Set Security Option.
3. Click on Advanced Config to continue.
4. Next to EAP Type, select EAP-TLS, LEAP, EAP-TTLS, or PEAP. Extensible
Authentication Protocols allow devices on the network to request authentication from
the RADIUS server in the network. All the devices on the network must use the same
EAP type when using a RADIUS server for authentication. Some RADIUS servers
require that the Validate Server field be selected. Check this field if your RADIUS
server requires validation.
5. Select an User Certificate from the drop-down menu.
6. Enter the login information required to authenticate.
7. Click AddtoentertheIPaddress(es)ofyourRADIUSservers.
8. Click OK to save your settings.

D-Link DWA-510 Specifications

General

Modulation	DBPSK
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2-PSK
Maximum data transfer rate	54 Mbit/s
Connectivity technology	Wireless
RX power consumption	260 mA
Gain	2 dBi
Link/Act LED	Yes
Dimensions (WxDxH)	126 x 12 x 19 mm
Compliance industry standards	IEEE 802.11g/b
Compatible operating systems	Windows 98SE, ME, 2000, XP, Vista
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Certification	FCC Class B, CE, C-Tick, IC, Wi-Fi, WPS
