<REMOVAL>
① Loosen the 6 washer screws and
remove the air cleaner case cover.
② Inspect the air cleaner element.
③ Install in the reverse order of removal.
<CLEANING>
●Clean the air cleaner element in clean
oil, squeeze excess oil, and then, wra-
pping it in a dry cloth, squeeze it again.
●Make sure all excess oil removed and
reassemble the air cleaner element.
OIL : SAE # 80 ~ 90
45
AIR CLEANER CASE COVER
AIR CLEANER ELEMENT INSPECTION
CAUTION
●Do not use gasoline or other ma-
terials having a low ignition point
as this can be a fire hazard.
●If the air cleaner element is in-
adequately assembled, dust and
other waste materials can directly
enter the engine. This results in
increased cylinder wear and redu-
ced power, and reduced durability
of the engine.
●When washing the vehicle, be
careful not to allow water to get
into the air cleaner.
Difficulties in starting the engine
may result if this happens.
●If the engine start is failed during
rain or after driving across water
pool, check to see if the water is
infiltrated in the air cleaner and
clean it.
●Do not drive in the flooded area. If
the water enters the air cleaner or
engine, the vehicle may be
subjected to the rear-end collision
due to the power failure.
SCREWS
**E-5 OWNERS(1~47) 02.11.5 4:3 PM 페이지45
