PLAYBACK
3130
On-Screen Display Overview
You can change the TV audio using the [AUDIO] button.
Press [AUDIO] repeatedly to change the TV audio, according to the Broadcast audio signal as shown below.
• STEREO Audio Signal :
Stereo ➝ Mono ➝ Stereo
• MONO Audio Signal :
Mono
• BIL Audio Signal :
BIL1 ➝ BIL2 ➝ BIL1
The current audio channel is displayed on-screen.
• If the sound is poor quality when set to Stereo, you can often improve it by changing to Mono.
• When an external input is selected, the audio channel can be switched only to Stereo.
Changing the TV Audio Channel
Changing TV Channels
If no disc is playing, you can change TV channels using the [0-9] or [PR+/-] buttons on the remote control or
[PR+/–] buttons on the front panel.
While watching TV, press [DISPLAY] to display/remove the on-screen display.
You would see a screen like the following:
Displaying TV Information
PR 1 : - - - -
STEREO
PDC
12:30
SP
DVD Playback
DVD Playback
When a DVD+RW or unfinalized DVD+R (-R, -RW)is inserted, no title is played automatically but the current TV
channel displays on the screen.
1 If you want to play a title on the DVD+R (+RW, -R, -RW), you must press
[MENU] or [PLAY] to display the disc menu of a thumbnail index for each
recorded title on the disc.
The index picture screen of the title will be displayed. Also title
information (name of recording, recorded day, time, recording quality)
will be displayed.
2 Select a title to play using [œ √] then press [ENTER] or [PLAY].
Playing a DVD+R (+RW, -R, -RW)
If a Disc menu is displayed
• A Disc menu may be displayed when you load a DVD. Use the [
œ √…†
] buttons to select the title/chapter you
want to view, then press [ENTER] to start playback. Press [TITLE] or [MENU] to return to the Disc menu.
• If the Parental Level feature is set and the disc is below the current Parental Level setting, the 4-digit code must
be entered and/or the disc must be authorized; see ‘Set Parental Level‘ on page 25.
• The DVD Recorder+VCR will not play discs with Region codes different from the DVD Recorder+VCR. The Region
code for this DVD Recorder+VCR is 2 (two).
• Unless stated otherwise, all operations described below use the remote control. Some features may also be
available in the Setup menu.
• A disc which is recorded by computer at high speeds (greater than or equal to 2x) may not be recognized.
• A disc which is recorded with unauthorized movie material may not be played.
• A disc which is recorded by other recorder or not recorded correctly may not be recognized or played.
1 Press [EJECT] to open the disc tray.
2 Load your disc in the tray with the playback side down (label side up).
3 Press [EJECT] to close the tray.
4
‘LOAD’ appears on the front panel display, and playback starts automatically. If playback does not start,
press [PLAY (
√
)]. In some cases, the Disc menu might appear instead.
Playing a DVD/VCD
Still Picture and Frame-by-Frame Playback
1
Press [PLAY/PAUSE] during playback. The DVD Recorder+VCR will go into Pause mode.
2
You can back up or advance the picture frame-by-frame by pressing [FF (√√ )] repeatedly during Pause
mode.
Fast Forward/Backward
1
Press [REW (œœ )] or [FF (√√ )] during playback. The DVD Recorder+VCR will go into Search mode.
2
Press [REW] or [FF] to select the desired speed: √√ X2, √√ X4, √√ X8, √√ X16, √√ X32,
√
(forward) or
œ
, œœ X2, œœ X4, œœ X8, œœ X16, œœ X32 (backward).
