PARTS DIAGRAM
§§
è
Parts List
NO. PART NAME PART CODE SPECIFICATION REMARK
A01 PLATE T 3614521500 PP
A02 DOOR B AS 3611797600 ABS OPTION :
A03 DOOR F AS 3611797700 ABS TRANSPARENT
A04 DOOR B 3611797300 PP OPTION :
A05 DOOR F 3611797400 PP NOT TRANSPARENT
A06
SPRING PLATE LEVER
3615111800 SUS
A07 PLATE LEVER 3614521400 PP
A08 SPRING DOOR 3615112100 SUS D1.4
A09 PANEL B 3614233400 PP
A10 CAP WATER - PP
OPTION :
A11 CAP DRY - PP
UPWARD WATER VALVE
A12 CONNECTOR HOSE 3619506600 PS
A13 PACKING 3614004100 SILICON
A14 PANEL B 3614233600 PP OPTION : BACKWARD
A15 PANEL F 3614233500 ABS
A16 CAP REAR 3610902600 CR
A17 NOZZLE DETERGENT 3618102600 PP
A18 CASE DETERGENT 3611130700 PP
A19 LEVER SAFETY S/W 3613701800 POM
A20
SPRING LEVER SAFETY
3615111700 SUS D1.0
A21 CLAMP 4507D08150 MFZN HOSE ID=7PIE
A22
SENSOR PRESSURE AS
3614801300 CDN-D6N
A23 SWITCH COVER AS 4507K44031 15A 220VAC 1006FD
3615403510 AC 100-130V/50,60Hz COLD
3615402010 AC 220V/60Hz COLD BACKWARD
A24 VALVE INLET 3615403711 AC 220-240V/50Hz COLD
3615403530 AC 100-130V/50,60Hz COLD
UPWARD
3615402030 AC 220V/60Hz COLD
3615403630 AC 100-130V/50,60Hz HOT
A25 VALVE INLET 3615402130 AC 220V/60Hz HOT BACKWARD
3615403831 AC 220-240V/50Hz HOT
3612787920 8A COLD BUBBLE
SINGLE VALVE
3612787925 5A COLD BUBBLE
3612787930 8A COLD/HOT BUBBLE
3612787935 5A COLD/HOT BUBBLE
DUAL VALVE, PUMP
3612787940 8A COLD/HOT NON-BUBBLE
A26 HARNESS AS
3612787945 5A COLD/HOT NON-BUBBLE
3612787970 8A COLD/HOT BUBBLE
3612787975 5A COLD/HOT BUBBLE
DUAL VALVE
3612787980 8A COLD/HOT NON-BUBBLE
3612787985 5A COLD/HOT NON-BUBBLE
