24
Switch Safety Ass’y
Replacing method from OLD type to NEW type.
Please use the “Special connector’ which will be supplied by Daewoo.
Switch Safety Ass’y
OLD type NEW type
Appearance
Structure lead wire type terminal type
Part name Part Cord Specification Part Cord Specification
Sensor pressure assy 3614800960 CDN-D7N 3614801110 D8T, TERMINAL
OLD type NEW type
Appearance
Structure lead wire type terminal type
Part name Part Cord Specification Part Cord Specification
Switch safety assy 3619003100 SF-040A 3619003101 SF-030A, CU/T=14mm
(DWF-8094, 7094) 3619003110 SF-040F 3619003111 SF-030S, CU/T=9mm
3619003130 SF-041A(DWF-8094PM) 3619003131
SF-031A, CU/T=9mm Australia
3619003120 SF-040Z(DWF-7094PM) 3619003121
SF-030Z, CU/T=14mm Australia
Switch safety assy 3619008920 SF-040T 3619008921 SF-030T, CU/T=0.5mm
(DWF-1094) 3619003190 SF-040A5 3619003191
SF-030T, CU/T=0.5mm Australia
Connector
To Next Page
