NO PARTS NAME PARTS CODE EA DESCRIPTION REMARK
A01 GASKET VALVE 3612300110 2 PVC-S
1EA;SINGLE VALVE
A02 PANEL B 3614218500 1 ABS
1
220V/60Hz
3615406660 DWF-7094CLE
VALVE INLET AS
1 220-240V/50Hz
(ONLY COLD) 3615406671 DWF-7094CNE
1 110-130V/60Hz
3615406650 DWF-7094CTE
A03
1 220V/60Hz
3615406600 DWF-7094PL
1 220-240V/50Hz
VALVE INLET AS
3615406631 DWF-7094PN
1
220-240V/50Hz
3615407600 (AUSTRALIA) DWF-7094PM
1 110-130V/60Hz
3615406620 DWF-7094PT
A05 HINGE DOOR 3612902400 2 POLYACETAL
A06 BUBBLE PUMP AS
3618918800
1
AC 110-130V/50,60Hz HOSE=500mm
3618919400 AC 220-240V/50,60Hz HOSE=500mm
A07 SENSOR PRESSURE 3614801110 1 D8T, TERMINAL
5EP1048010 T5-V1
AC 110-130V
A08 TRANS POWER
5EP1048020
1
T5-V1F
5EP1048030 T5-V2
AC 220-240V
5EP1048040 T5-V2F
3619003101
SF-030A, CU/T=14, #1877094
SWITCH SAFETY AS
3619003111
1
SF-030S, CU/T=9, #187
7094CLE
A09
3619003121
SF-030Z, CU/T=14, #187
7094(AUSTRALIA)
A10 PLATE T 3614514800 1 ABS
A11 CAP SOFTENER 3610907800 1 PP
A12 NOZZLE DETERGENT 3618101700 1 PP
A13 CASE DETERGENT 3611114700 1 PP
A14 SPRING DOOR 3615107910 1 SUS304 D=1.8
A15 DOOR B 3611718200 1 ABS
A16 DOOR F 3611718100 1 ABS
A17 HANDLE DOOR 3612603500 1 ABS
A18 – – – –
A19 SPECIAL BOLT 3616001200 2 T1 TRS 5x73
41
PARTS DIAGRAM
§§
è
Parts List
1. DWF-7094
