Dahua 32 Series User Manual

12
2 System Performance
This series product max supports 16-channel standard definition video/high definition non-real-time
video and the transmission rate is 2mbps per channel. It can also max supports 4-channel high
definition video and the transmission rate is 8mbps. The delay time of each channel is below 500ms.
Model System Performance
4-ch series Max support 4-channel video.
Total resources:400/480fps@D1,200/240fps@720P.100/120@1080P.
8-ch series Max support 8-channel video.
Total resources:400/480fps@D1,200/240fps@720P.100/120@1080P.
16-ch series Max support 16-channel video.
Total resources:400/480fps@D1,200/240fps@720P.100/120@1080P.
Important
z The standard definition device here is referring to the devices of D1 resolution or below.
z The high definition device here is referring to the devices of 702P resolution or higher.

Dahua 32 Series Specifications

General

Brand	Dahua
Model	32 Series
Category	DVR
Language	English
