Dahua VTO4202F Series User Manual

Configuration 23
Parameter
Description
Nick Name
Room No.
The room number you planned.
 If you use multiple VTH devices, the room number of the master VTH
should be "room number#0", and the room number of the extension
VTH should be "room number#1", "room number#2", …, "room
number#99".
 You can have 10 extension VTH devices at most for one master VTH.
Register Type
Select public, and local is reserved for future use.
Register
Password
Keep the default value.
3) Click Save.
The added room number is displayed. Click to modify room information, and click
to delete a room.
 Adding room number in batches
1) Configure the Unit Layer Amount, Room Amount in One Layer, First Floor Number,
and Second Floor Number according to the actual condition.
2) Click the Add at the bottom. See Figure 4-13
Add in batch Figure 4-13
All the added room numbers are displayed. Click Refresh to view the latest status,
and click Clear to delete all the room numbers.
4.2.7 Configuring Module
Camera module is designed by default. All other modules need to be added in facade layout
before use.
 You can add 9 modules at most to VTO4202F-MB1, VTO4202F-MB2, VTO4202F-MB5.
For VTOs of other modules, you can only add one module.
 For fingerprint module, card swiping module, and keyboard module, only one module of
each type can be added respectively. Other modules can be matched freely.
4.2.7.1 Adding Modules
Select Local Setting > Basic > Façade Layout. Step 1
The Façade Layout interface is displayed. See Figure 4-14.
