Daikin 2MXS-N Series User Manual

EDUS121503A Capacity Tables
Multi-Split Type Air Conditioners 2/3/4MXS-N Series 149
1
FTXS15L 68.0 18.44 1.17 19.27 1.20 20.10 1.22 20.51 1.23 21.76 1.27 22.59 1.29
77.0 17.60 1.24 18.43 1.27 19.26 1.29 19.68 1.30 20.92 1.34 21.75 1.36
86.0 16.76 1.32 17.59 1.34 18.42 1.37 18.84 1.38 20.08 1.41 20.91 1.44
89.6 16.43 1.35 17.26 1.38 18.09 1.40 18.50 1.41 19.75 1.45 20.58 1.47
95.0 15.93 1.40 16.76 1.43 17.59 1.45
18.00 1.46 19.24 1.50 20.07 1.52
104.0 15.09 1.49 15.92 1.52 16.75 1.54 17.16 1.55 18.41 1.59 19.24 1.61
109.4 14.59 1.55 15.42 1.57 16.24 1.60 16.66 1.61 17.90 1.64 18.73 1.67
114.8 9.88 0.98 10.30 0.98 10.72 0.98 10.92 0.98 11.51 0.98 11.90 0.98
CDXS15L 68.0 15.98 1.20 16.70 1.22 17.42 1.24 17.78 1.26 18.86 1.29 19.58 1.32
77.0 15.26 1.27 15.97 1.29 16.69 1.32 17.05 1.33 18.13 1.36 18.85 1.39
86.0 14.53 1.35 15.25 1.37 15.97 1.39 16.33 1.41 17.40 1.44 18.12 1.47
89.6 14.24 1.38 14.96 1.40 15.68 1.43 16.04 1.44 17.11 1.48 17.83 1.50
95.0 13.80 1.43 14.52 1.46 15.24 1.48
15.60 1.49 16.68 1.53 17.40 1.55
104.0 13.08 1.52 13.80 1.55 14.51 1.57 14.87 1.58 15.95 1.62 16.67 1.64
109.4 12.64 1.58 13.36 1.61 14.08 1.63 14.44 1.64 15.52 1.68 16.23 1.70
114.8 8.65 0.98 9.01 0.98 9.37 0.98 9.55 0.98 10.07 0.98 10.40 0.98
FTXS18L 68.0 22.13 1.53 23.12 1.56 24.12 1.59 24.62 1.60 26.11 1.65 27.11 1.68
77.0 21.12 1.62 22.12 1.65 23.11 1.68 23.61 1.69 25.10 1.74 26.10 1.77
86.0 20.12 1.72 21.11 1.75 22.11 1.78 22.61 1.79 24.10 1.84 25.09 1.87
89.6 19.72 1.76 20.71 1.79 21.71 1.82 22.20 1.84 23.70 1.88 24.69 1.91
95.0 19.11 1.83 20.11 1.86 21.10 1.89
21.60 1.90 23.09 1.95 24.09 1.98
104.0 18.11 1.94 19.10 1.97 20.10 2.00 20.59 2.02 22.09 2.06 23.08 2.09
109.4 16.27 1.77 17.01 1.77 17.74 1.77 18.09 1.77 19.14 1.77 19.81 1.77
114.8 10.18 0.98 10.59 0.98 10.99 0.98 11.19 0.98 11.76 0.98 12.13 0.98
CDXS18L 68.0 18.55 1.43 20.13 1.56 20.99 1.59 21.43 1.60 22.73 1.65 23.59 1.68
77.0 18.39 1.62 19.25 1.65 20.12 1.68 20.55 1.69 21.85 1.74 22.72 1.77
86.0 17.51 1.72 18.38 1.75 19.24 1.78 19.68 1.79 20.97 1.84 21.84 1.87
89.6 17.16 1.76 18.03 1.79 18.89 1.82 19.33 1.84 20.62 1.88 21.49 1.91
95.0 16.63 1.83 17.50 1.86 18.37 1.89
18.80 1.90 20.10 1.95 20.97 1.98
104.0 15.76 1.94 16.63 1.97 17.49 2.00 17.92 2.02 19.22 2.06 20.09 2.09
109.4 14.28 1.77 14.94 1.77 15.58 1.77 15.90 1.77 16.83 1.77 17.43 1.77
114.8 9.15 0.98 9.52 0.98 9.87 0.98 10.05 0.98 10.56 0.98 10.89 0.98
FTXS24L 68.0 27.83 2.05 30.83 2.34 32.16 2.39 32.82 2.41 34.81 2.48 36.14 2.53
77.0 27.83 2.38 29.49 2.48 30.82 2.53 31.48 2.55 33.47 2.62 34.80 2.66
86.0 26.82 2.59 28.15 2.63 29.48 2.68 30.14 2.70 32.13 2.77 33.46 2.81
89.6 26.29 2.65 27.61 2.70 28.94 2.74 29.60 2.76 31.59 2.83 32.92 2.88
95.0 25.48 2.75 26.81 2.79 28.14 2.84
28.80 2.86 30.79 2.93 32.12 2.98
104.0 23.04 2.56 24.10 2.56 25.13 2.56 25.64 2.56 27.13 2.56 28.09 2.56
109.4 18.21 1.77 18.93 1.77 19.64 1.77 19.99 1.77 21.02 1.77 21.68 1.77
114.8 11.41 0.98 11.81 0.98 12.20 0.98 12.39 0.98 12.96 0.98 13.32 0.98
CDXS24L 68.0 24.47 2.04 26.76 2.28 27.92 2.32 28.49 2.34 30.22 2.41 31.37 2.45
77.0 24.45 2.37 25.60 2.41 26.75 2.46 27.33 2.48 29.06 2.54 30.21 2.59
86.0 23.28 2.51 24.44 2.56 25.59 2.60 26.16 2.62 27.89 2.69 29.04 2.74
89.6 22.82 2.58 23.97 2.62 25.12 2.66 25.70 2.69 27.43 2.75 28.58 2.80
95.0 22.12 2.67 23.27 2.72 24.42 2.76
25.00 2.78 26.73 2.85 27.88 2.89
104.0 20.35 2.56 21.32 2.56 22.26 2.56 22.72 2.56 24.08 2.56 24.96 2.56
109.4 16.44 1.77 17.10 1.77 17.75 1.77 18.07 1.77 19.00 1.77 19.61 1.77
114.8 10.48 0.98 10.84 0.98 11.20 0.98 11.37 0.98 11.89 0.98 12.22 0.98
Combination
(Capacity)
Outdoor air
temp.
EDB (°F)
Indoor air temp. EWB (°F)
57.2 60.8 64.4 67.0 71.6 75.2
TC PI TC PI TC PI TC PI TC PI TC PI
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
