Piping Diagrams EDUS121503A
88 Multi-Split Type Air Conditioners 2/3/4MXS-N Series
6. Piping Diagrams
6.1 Indoor Unit
CTXG09/12QVJUW(S) CTXG18QVJUW(S)
CTXS07LVJU, FTXS09/12LVJU FTXS15/18LVJU
4D101008
4D101010
INDOOR UNIT
1/4 CuT
HEAT EXCHANGER
CROSS FLOW FAN
THERMISTOR
ON HEAT EXCH.
FIELD PIPING
1/4 CuT
M
FAN MOTOR
FIELD PIPING
3/8 CuT
CuT3/8
REFRIGERANT FLOW
COOLING
HEATING
4D074606
INDOOR UNIT
5/16 CuT
DISTRIBUTOR
HEAT EXCHANGER
CROSS FLOW FAN
FIELD PIPING
1/4 CuT
M
FAN MOTOR
HEADER
FIELD PIPING
1/2 CuT
1/2 CuT
REFRIGERANT FLOW
COOLING
HEATING
THERMISTOR
ON HEAT EXCH.
4D074609
