Daikin 2MXS-N Series User Manual

Specifications EDUS121503A
36 Multi-Split Type Air Conditioners 2/3/4MXS-N Series
C: 3D093891
C: 3D093892
C: 3D093893
C: 3D093894
C: 3D093895
09+12+12 Duct Duct Duct — 6.06 8.47 8.47 — 23.00 9.00 ~ 32.00 1720 610 ~ 2840 7.6 2.7 ~ 12.6 98
09+12+15 Wall Wall Wall — 5.45 7.64 10.91 — 24.00 8.20 ~ 36.00 1690 440 ~ 3140 7.5 2.0 ~ 13.9 98
09+12+15 Wall Wall Duct — 5.39 7.54 10.77 — 23.70 8.40 ~ 34.70 1640 570 ~ 2910 7.3 2.5 ~ 12.9 98
09+12+15 Wall Duct Wall — 5.39 7.54 10.77 — 23.70 8.40 ~ 34.70 1610 480 ~ 2850 7.1 2.1 ~ 12.6 98
09+12+15 Wall Duct Duct — 5.30 7.41 10.59 — 23.30 8.60 ~ 33.30 1670 620 ~ 2800 7.4 2.8 ~ 12.4 98
09+12+15 Duct Wall Wall — 5.39 7.54 10.77 — 23.70 8.30 ~ 34.70 1630 480 ~ 2870 7.2 2.1 ~ 12.7 98
09+12+15 Duct Wall Duct — 5.30 7.41 10.59 — 23.30 8.60 ~ 33.30 1660 620 ~ 2780 7.4 2.8 ~ 12.3 98
09+12+15 Duct Duct Wall — 5.30 7.41 10.59 — 23.30 8.50 ~ 33.30 1560 530 ~ 2670 6.9 2.4 ~ 11.8 98
09+12+15 Duct Duct Duct — 5.23 7.32 10.45 — 23.00 8.80 ~ 32.00 1730 690 ~ 2800 7.7 3.1 ~ 12.4 98
09+12+18 Wall Wall Wall — 5.00 7.00 12.00 — 24.00 8.20 ~ 36.00 1710 450 ~ 3110 7.6 2.0 ~ 13.8 98
09+12+18 Wall Wall Duct — 4.94 6.91 11.85 — 23.70 8.40 ~ 34.70 1630 560 ~ 2900 7.2 2.5 ~ 12.9 98
09+12+18 Wall Duct Wall — 4.94 6.91 11.85 — 23.70 8.30 ~ 34.70 1620 480 ~ 2860 7.2 2.1 ~ 12.7 98
09+12+18 Wall Duct Duct — 4.85 6.80 11.65 — 23.30 8.60 ~ 33.30 1660 610 ~ 2790 7.4 2.7 ~ 12.4 98
09+12+18 Duct Wall Wall — 4.94 6.91 11.85 — 23.70 8.30 ~ 34.70 1630 480 ~ 2880 7.2 2.1 ~ 12.8 98
09+12+18 Duct Wall Duct — 4.85 6.80 11.65 — 23.30 8.60 ~ 33.30 1650 610 ~ 2770 7.3 2.7 ~ 12.3 98
09+12+18 Duct Duct Wall — 4.85 6.80 11.65 — 23.30 8.50 ~ 33.30 1560 530 ~ 2680 6.9 2.4 ~ 11.9 98
09+12+18 Duct Duct Duct — 4.79 6.71 11.50 — 23.00 8.80 ~ 32.00 1720 680 ~ 2790 7.6 3.0 ~ 12.4 98
09+15+15 Wall Wall Wall — 4.80 9.60 9.60 — 24.00 8.20 ~ 36.00 2020 490 ~ 3130 9.0 2.2 ~ 13.9 98
09+15+15 Wall Wall Duct — 4.74 9.48 9.48 — 23.70 8.30 ~ 34.70 1760 580 ~ 3080 7.8 2.6 ~ 13.7 98
09+15+15 Wall Duct Duct — 4.66 9.32 9.32 — 23.30 8.50 ~ 33.30 1740 710 ~ 2860 7.7 3.1 ~ 12.7 98
09+15+15 Duct Wall Wall — 4.74 9.48 9.48 — 23.70 8.20 ~ 34.70 1830 510 ~ 3110 8.1 2.3 ~ 13.8 98
09+15+15 Duct Wall Duct — 4.66 9.32 9.32 — 23.30 8.40 ~ 33.30 1710 620 ~ 2800 7.6 2.8 ~ 12.4 98
09+15+15 Duct Duct Duct — 4.60 9.20 9.20 — 23.00 8.60 ~ 32.00 1770 770 ~ 2760 7.9 3.4 ~ 12.2 98
12+12+12 Wall Wall Wall — 8.00 8.00 8.00 — 24.00 8.40 ~ 36.00 1550 430 ~ 2990 6.9 1.9 ~ 13.3 98
12+12+12 Wall Wall Duct — 7.90 7.90 7.90 — 23.70 8.50 ~ 34.70 1550 480 ~ 2820 6.9 2.1 ~ 12.5 98
12+12+12 Wall Duct Duct — 7.77 7.77 7.77 — 23.30 8.80 ~ 33.30 1600 540 ~ 2760 7.1 2.4 ~ 12.2 98
12+12+12 Duct Duct Duct — 7.67 7.67 7.67 — 23.00 9.00 ~ 32.00 1720 610 ~ 2840 7.6 2.7 ~ 12.6 98
12+12+15 Wall Wall Wall — 7.00 7.00 10.00 — 24.00 8.20 ~ 36.00 1730 450 ~ 3140 7.7 2.0 ~ 13.9 98
12+12+15 Wall Wall Duct — 6.91 6.91 9.89 — 23.70 8.40 ~ 34.70 1690 570 ~ 2920 7.5 2.5 ~ 13.0 98
12+12+15 Wall Duct Wall — 6.91 6.91 9.89 — 23.70 8.30 ~ 34.70 1630 480 ~ 2870 7.2 2.1 ~ 12.7 98
12+12+15 Wall Duct Duct — 6.80 6.80 9.70 — 23.30 8.60 ~ 33.30 1660 620 ~ 2780 7.4 2.8 ~ 12.3 98
12+12+15 Duct Duct Wall — 6.80 6.80 9.70 — 23.30 8.50 ~ 33.30 1560 530 ~ 2670 6.9 2.4 ~ 11.8 98
12+12+15 Duct Duct Duct — 6.71 6.71 9.58 — 23.00 8.80 ~ 32.00 1730 690 ~ 2800 7.7 3.1 ~ 12.4 98
Combination
of
indoor unit
Type of indoor unit
Capacity of each indoor unit
Each capacity (kBtu/h) Total capacity (kBtu/h) Total input (W) Total current (A)
Power
factor (%)
A room B room
C room — A room B room C room — Rating ( min ~ max ) Rating ( min ~ max ) Rating ( min ~ max ) Rating
Notes:
1. Cooling capacity is based on 80°FDB (26.7°CDB) / 67°FWB (19.4°CWB) (Indoor temperature), 95°FDB
(35°CDB) / 75°FWB (24°CWB) (Outdoor temperature).
Heating capacity is based on 70°FDB (21°CDB) / 60°FWB (15.6°CWB) (Indoor temperature), 47°FDB
(8.3°CDB) / 43°FWB (6°CWB) (Outdoor temperature).
2. The total ability of connected indoor units is up to 39.0 kBtu/h.
3. It is impossible to connect the indoor unit for one room only.
4. The above is the value for connecting with the following indoor units.
7.0 kBtu/h class; wall mount type L series
9.0 kBtu/h class; wall mount type L series or Duct type L series
12.0 kBtu/h class; wall mount type L series or Duct type L series
15.0 kBtu/h class; wall mount type L series or Duct type L series
18.0 kBtu/h class; wall mount type L series or Duct type L series
