Daikin 2MXS-N Series User Manual

Dimensions EDUS121503A
74 Multi-Split Type Air Conditioners 2/3/4MXS-N Series
CTXS07LVJU, FTXS09/12LVJU
FTXS15/18LVJU
FRONT GRILLE
FIXED SCREWS
(INSIDE)
FLAPS
WIRELESS REMOTE CONTROLLER
(ARC452A21)
(SPACE FOR PERFORMANCE)
(SPACE FOR
MAINTENANCE)
(SPACE FOR MAINTENANCE)
INTELLIGENT EYE SENSOR
SIGNAL RECEIVER
OPERATION LAMP
DRAIN HOSE
(CONNECTING PART
O.D. φ5/8 (φ16mm)
THE HOSE LENGTH OF OUTSIDE
THE UNIT IS APPROX. 18-5/16 (465mm))
GAS PIPE φ3/8 (φ9.5mm) CuT
(THE LENGTH OF PIPE OUTSIDE
THE UNIT: ABOUT 13-3/4 (350mm))
TIMER LAMP
INTELLIGENT EYE LAMP
LIQUID PIPE φ1/4 (φ6.4mm) CuT
(THE LENGTH OF PIPE OUTSIDE
THE UNIT: ABOUT 15-3/4 (400mm))
SIGNAL TRANSMITTER
STANDARD LOCATIONS OF WALL HOLES
AIRFLOW (INDOOR)
INCLUDING
MOUNTING PLATE
)(
REQUIRED SPACE
NAME PLATE
TERMINAL BLOCK
WITH GROUND
TERMINAL
INDOOR UNIT ON/OFF SWITCH
ROOM TEMP. THERMISTOR (INSIDE)
MODEL NAME PLATE
BLADE ANGLES
UP/DOWN
(AUTOMATIC)
WALL HOLE
φ2-9/16 (φ65mm) HOLE
WALL HOLE FOR
EMBEDDED PIPING
φ2-9/16 (φ65mm) HOLE
31-1/2 (800mm)
REAR
RIGHT
LEFT
1-3/16 (30mm) MIN
8-9/16 (217mm)
1-15/16 (50mm) MIN
8-7/16 (215mm)
1-15/16 (50mm) MIN
11-5/8 (295mm)
BOTTOM
31-1/2 (800mm)
23-1/16 (586mm)
9/16 (14.5mm)
5-3/4 (145.5mm)
2-5/16 (58mm) 11/16 (18mm)
FAN
COOLING, DRY
HEATING
5°
15°
1-3/4 (44.5mm)
1-3/4 (44.5mm)
11-5/8 (295mm)
30°
35°
30°
30°
7-3/8 (187mm)
65°
55°
65°
45°
70°
80°
2-3/8 (60mm)
2-5/16 (59.5mm)
RIGHT/LEFT
(AUTOMATIC)
45
°
45°
THE MARK (→) SHOWS PIPING DIRECTION
C: 3D074094A
DRAIN HOSE
(CONNECTING PART
O.D. φ5/8 (φ16mm)
THE HOSE LENGTH OF OUTSIDE
THE UNIT: ABOUT 18-5/16 (465mm))
SIGNAL
TRANSMITTER
11/16 (18mm)2-5/16 (58mm)
UP/DOWN
(AUTOMATIC)
FAN
COOLING, DRY
HEATING
15°
15°
25°
30°
7-3/8 (187mm)
25°
40°
75°
50°
60°
75°
70°
70°
WIRELESS REMOTE CONTROLLER
(ARC452A21)
41-5/16 (1050mm)
9-13/16 (250mm)
9-3/4 (248mm)
MIN.1-15/16 (50mm)
MIN.1-15/16 (50mm)
13-3/8 (340mm)
41-5/16 (1050mm)
9/16 (14.5mm)
1-3/8 (35.5mm)37-5/16 (947mm)
5/8 (16mm)
8-1/4 (210mm)
13-3/8 (340mm)
1-3/4 (45mm)
3-1/2 (89mm)2-9/16 (65mm)
1-3/4 (45mm)
45°
45°
THE MARK ( → )SHOWS PIPING DIRECTION
AIRFLOW (INDOOR)
REAR
LEFT
RIGHT
INCLUDING
INSTALLATION PLATE
(SPACE FOR
MAINTENANCE)
(SPACE FOR
MAINTENANCE)
REQUIRED SPACE
NAME PLATE
INTELLIGENT EYE SENSOR
BOTTOM
SIGNAL RECEIVER
FLAPS
OPERATION LAMP
TIMER LAMP
INTELLIGENT EYE LAMP
INDOOR UNIT ON/OFF
SWITCH
MODEL NAME PLATE
BLADE ANGLES
RIGHT/LEFT (AUTOMATIC)
MIN.1-3/16 (30mm)
(SPACE FOR
PERFORMANCE)
FRONT
GRILLE
FIXING
SCREWS
(INSIDE)
TERMINAL BLOCK
WITH
GROUND TERMINAL
(INSIDE)
GAS PIPE φ1/2 (φ12.7mm) CuT
(THE LENGTH OF PIPE OUTSIDE
THE UNIT: ABOUT 15-3/4 (400mm))
LIQUID PIPE φ1/4 (φ6.4mm) CuT
(THE LENGTH OF PIPE OUTSIDE
THE UNIT: ABOUT 18-1/8 (460mm))
ROOM TEMP. THERMISTOR
(INSIDE)
WALL HOLE
φ3-1/8 (φ80mm) HOLE
WALL HOLE FOR EMBEDDED
PIPING φ3-1/8 (φ80mm) HOLE
STANDARD LOCATIONS OF WALL HOLES
( )
C: 3D074024A
