Sensor Kit for FFQ Series SiUS121736EA
39 Printed Circuit Board Connector Wiring Diagram
2. Sensor Kit for FFQ Series
2.1 BRYQ60A2W(S)
Outline
Thermopile
Sensor (A4P)
Pyroelectric
Sensor (A5P)
Thermopile sensor
(A4P)
Pyroelectric sensor
(A5P)
(R25074)
Connector
3P262610-1
Connector
3P262611-1
