Daikin DC97MC User Manual

62
Troubleshooting
ComfortNet
Thermostat Only
Symptoms of Abnormal Operation
(Non-communicating & ComfortNet™
Thermostat)
Diagnostic/Status
LEDCodes
Fault Description
Message Code
Possible Causes Corrective Actions Notes & Cautions
Furnace fails to operate Integrated control module LED display provides IF error code.. ComfortNet thermostat “Call for Service” icon illuminated ComfortNet thermostat scrolls “Check Furnace”message
if
Integrated control modulehas an internal fault
INTERNAL
FAULT
EE
Improper wiring to the furnace
or integrated control module.
Assure proper wiring to furnace and integrated control module. Verify power to thefurnaceand
integrated control module is stable and within specifications.
Replacebad integrated control module.
TurnpowerOFFpriorto repair. Readprecautionsin “Electrostatic Discharge” section of manual. Replaceintegrated control module with current replacement parts.
LED display indicates O
n
O
n
Normal operation
None None
Normal operation None Normal operation
Furnace fails to operate Integrated control module LED display provides E
0error code.
ComfortNetthermostat“Call for Service” icon illuminated. ComfortNet thermostat scrolls “Check Furnace”message.
E0
Furnace lockoutdue to an excessive number of ignition “retries” or flame “recycles” (3 total).
LOCKOUT E0
Failure to establishflame. Cause may be no gas to burners, front cover pressure switch stuck open, bad igniter or igniter alignment, improperorifices, or coated/oxidized or improperly connected flame sensor. Loss of flame after establishment. Cause may be interrupted gas supply, lazy burner flames (improper gas pressure or restriction in flue and/or combustion air piping), front cover pressure switch opening, or improper induced draft blower performance.
Locateandcorrect gas interruption. Check front cover pressure switch operation (hose, wiring, contact operation). Correct if necessary. Makesure furnaceis draining properly. Replaceor realignigniter. Check flame sensesignal. Clean sensor if coated and/or oxidized. Check flue piping for blockage, proper length, elbows, and termination. Verify proper induced draft blower performance.
TurnpowerOFFpriorto repair. Igniter is fragile, handle withcare. Clean flame rod with steel wool. See “Vent/FluePipe” section for piping details.
Furnace fails to operate. Integrated control module LED display provides E
1error code.
ComfortNetthermostat“Call for Service” icon illuminated. ComfortNet thermostat scrolls “Check Furnace”message.
E1
Low stage pressure switch circuit is closed at start of heatingcycle.
PS1
CLOSED
E1
Low stage pressure switch contacts sticking. Shorts in pressure switch circuit wiring.
Replacelow stage pressure switch. Repair short in wiring.
TurnpowerOFFpriorto repair. Replacepressure switch with correct replacement part.
Induced draft blower runs continuously with no further furnace operation. Integrated control module LED display provides E
2error code.
ComfortNetthermostat“Call for Service” icon illuminated. ComfortNet thermostat scrolls “Check Furnace”message.
E2
Low stage pressure switch circuit is not closed.
PS1 OPEN E2
Pressure switch hose blocked pinched, or connected improperly. Blocked flue and/or inlet air pipe, blocked drain system or weak induced draft blower. Incorrect pressureswitch setpoint or malfunctioning switch contacts. Loose or improperly connected wiring. Inducer not running. H fitting atmospheric port blocked.
Inspect pressure switch hose. Repair/replace if necessary. Inspect flue and/or inlet air piping for blockage, proper length, elbows, and termination. Check drainsystem. Correct as necessary. Check induced draft blower performance.Correct as necessary. Correct pressure switch set point or contact motion. Tighten or correct wiring connection. Clean H fitting.
TurnpowerOFFpriorto repair. Replacepressure switch with correct replacement part. Replaceinduced draft blower with correct replacement part. Take careto assemble/install H fitting in factory configuration.
