ESIE09-05 Specifications
Specifications 9
Symbols:
Refrigerant oil
Type Daphne FVC68D
Charged volume l 1.5 1.5 1.5
Piping
connections
Liquid
Type Flare connection Flare connection Flare connection
Diameter
(OD)
mm 9.52 9.52 9.52
Gas
Type Flare connection Flare connection Braze connection
Diameter
(OD)
mm 15.9 15.9 19.1
Drain
Quantity 3 3 3
Diameter
(OD)
mm 26 × 3 26 × 3 26 × 3
Heat insulation Both liquid and gas pipes
Max total length m 55 55 55
Defrost method Reversed cycle
Defrost control Sensor for outdoor heat exchanger temperature
Capacity control method Inverter controlled
Capacity control [%] 24 to 100
Safety devices HPS
Safety devices Fan motor thermal protection
Safety devices Inverter overload protector
Safety devices PC board fuse
Standard
accessories
Item Installation manual
Quantity 1 1 1
Standard
accessories
Item Operation manual
Quantity 1 1 1
Standard
accessories
Item Connection pipes
Quantity 3
Notes Nominal cooling capacities are based on: indoor temperature: 27°CDB/19°CWB, outdoor temperature: 35°CDB,
equivalent refrigerant piping: 7,5m, level difference: 0m.
Nominal heating capacities are based on: indoor temperature: 20°CDB, outdoor temperature: 7°CDB/6°CWB,
equivalent refrigerant piping: 7,5m, level difference: 0m.
Sound pressure level is a relative value, depending on the distance and acoustic environment. For more details,
please refer to sound level drawings.
Sound values are measured in a semi-anechoic room.
TECHNICAL SPECIFICATIONS ERQ100A7V1B ERQ125A7V1B ERQ140A7V1B
ELECTRICAL SPECIFICATIONS ERQ100A7V1B ERQ125A7V1B ERQ140A7V1B
Power supply Name V1
Phase 1N~
Frequency Hz 50
Voltage V 220-240
Current Nominal running current in
cooling (RLA)
A
15,9 20,2 22,2
Starting current (MSC) A 15,9 20,2 22,2
Zmax
Ω
No requirements
Minimum Ssc
(2)
value kVA Equipment complying with EN/IEC 61000-3-12
(1)
Maximum running current
(RLA)
A
27,0
Min circuit amps (MCA) A 27,0
Max fuse amps (MFA) A 32,0
Full load amps (FLA) A 0,3 + 0,3 (Fan motor)
Voltage range Minimum V 198
Maximum V 264
Wiring
connections
For power
supply
Quantity 3
Remark Earth wire included
For
connection
with AHU
Quantity 2
Remark
F1 + F2
Power supply intake Both AHU and outdoor unit
Field earth leakage breaker mA 300
Notes (1) European/international technical standard setting the limits for harmonic currents produced by equipment connected to public low voltage system with
input current > 16A and
≤ 75A per phase.
(2) Short-circuit power.
MCA Minimum Circuit Amps
MFA Maximum Fuse Amps (see note 5)
RLA Rated Load Amps
FLA Full Load Amps
MSC Starting Current (see note 6)
