17
INTELLIGENT EYE Operation
NOTE
Notes on INTELLIGENT EYE operation
Application range is as follows.•
90°
55°
7m
55°
Vertical angle 90°
(Side view)
Horizontal angle 110°
(Top view)
7m
Sensor may not detect moving objects further than 7m away. (Check the application range.)•
Sensor detection sensitivity changes according to indoor unit location, the speed of passersby, temperature range, etc.•
The sensor also mistakenly detects pets, sunlight, fl uttering curtains and light refl ected off of mirrors as passersby.•
INTELLIGENT EYE operation will not go on during POWERFUL operation.•
NIGHT SET mode •
Page 21
will not go on during use of INTELLIGENT EYE operation.
CAUTION
Do not place large objects near the sensor.•
Also keep heating units or humidifi ers outside the sensor’s detection area. This sensor can detect undesirable objects.
Do not hit or violently push the INTELLIGENT EYE sensor. This can lead to damage and malfunction.•
[Example]
When someone is in the
room
Normal operation
The air conditioner is in normal •
operation while the sensor is
detecting the movement of people.
When no one is in the room
20 minutes after, start energy
saving operation.
The set temperature is shifted in •
±2°C steps.
Someone is back in the
room
Back to normal operation.
The air conditioner will return to •
normal operation when the sensor
detects the movement of people
again.
INTELLIGENT EYE operation is useful for energy saving
Energy saving operation
If no presence detected in the room for 20 minutes, the energy saving operation will start.•
This operation changes the temperature –2°C in HEAT / +2°C in COOL / +1°C in DRY operation from set temperature.•
This operation decreases the airfl ow rate slightly in FAN operation only.•
