ESIE15-11A | Part 2. Troubleshooting 1. How to retrieve error code and data?
Page 12 23/09/16
VRV4 indoor units
Normal display (No display)
Inspection/test
operation
Press the button.
Error code blinks when an error occurs.
Unit
Error code
Inspection
0
L 0
Unit
Error code
Inspection
0
L 0
Inspection mode
Inspection/test
operation
Press the button.
0 7 1
F C J
Indoor unit model code display
Press the button.
Inspection/test
operation
? – – –
A A 1
Outdoor unit model code display
Press the button.
Inspection/test
operation
Test operation
Test operation mode
Press the button.
Inspection/test
operation
Capacity code
Indoor unit system code
Indoor unit type code
Progression code
0 7 1...
F...
C...
J...
Example of capacity code display
Example model Display
FXCQ25 028
FXFQ63 071
Indoor unit system code
Indoor unit type code
Display Product classification System classification
1 VRV system (VAV indoor unit)
2 VRV system
Outdoor air processing unit
F VRV system Standard indoor unit
H VRV system
New ceiling suspended cassette
Display Type Model
A Wall mounted FXAQ
C 2-way blow FXCQ
E Corner FXKQ
F Round flow FXFQ
H Ceiling suspended FXHQ
J Concealed ceiling FXSQ
P Floor standing FXLQ
U Concealed ceiling FXMQ
L
Concealed floor standing type
FXNQ
6 600×600 4-way blow FXZQ
3 Slim concealed ceiling FXDQ
Outdoor model code
Display Type Model
A A 1
VRV System Inverter K Series RSXYP
A A 3
R-407C VRV PLUS Series RXYP
A 9 2
VRV Heat Recovery Series RSEYP
A A 5
High COP type R-407C L Series RSXYP-L
A A A
VRV II RXYQ-M
A A C
VRV II M/C RXYQ-MA
A A E
VRV III Heat Pump Series RXYQ-P
Cooling Only Series RXQ-P
A 9 E
VRV III Heat Recovery Series REYQ-P
A 5 E
VRV III-C Heat Pump Series RTSYQ-PA
