ESIE15-11A | Part 3. Field settings 6. General indoor units
23/09/16 Page 41
VRV4 indoor units
6. General indoor units
These settings are applicable to most of the indoor units.
10 /
20
0 Filter contamination (time between 2
filter cleaning display indications)
01 light Ultra-long life Filter: +/-10.000 hrs
Long-life filter +/-2.500 hrs
Standard filter +/-200 hrs
02 heavy Ultra-long life Filter: +/-5.000 hrs
Long-life filter +/-1.250 hrs
Standard filter +/-100 hrs
1 Long life filter type 01
long life filter Filterclass G1
02 super long life filter
(option)
Filter type F6 high efficiency 64 for
FXCQ-FXUQ-FXFQ-FXZQ-FXKQ-
FXSQ-FXDQ-FXFQ-FXMQ
Filter type F7 for VAM (additional filter)
Filter type F8 very high efficiency 90
for FXCQ-FXFQ-FXSQ-FXMQ
04 oil guard filter for installations in greasy environment
2 Indoor thermostat sensor selection
(no effect when used in conjunction
with presence sensor BRYQ)
01
Use both the unit sensor
(or remote sensor if
installed) AND the remote
controller sensor.
Note: If setting 10-6-02 + 10-2-01 or
10-2-02 or 10-2-03 are set at the
same time, then setting 10-2-01,
10-2-02 or 10-2-03 have priority.
Note: If setting 10-6-01 + 10-2-01 or
10-2-02 or 10-2-03 are set at the
same time, then setting for group con-
nection, 10-6-01 has priority and for
individual connection, 10-2-01,
10-2-02 or 10-2-03 have priority.
02 Use return air sensor only
(or remote sensor if
installed).
Note: If setting 10-6-02 + 10-2-01 or
10-2-02 or 10-2-03 are set at the
same time, then setting 10-2-01,
10-2-02 or 10-2-03 have priority.
Note: If setting 10-6-01 + 10-2-01 or
10-2-02 or 10-2-03 are set at the
same time, then setting for group con-
nection, 10-6-01 has priority and for
individual connection, 10-2-01,
10-2-02 or 10-2-03 have priority.
03 Use remote controller sen-
sor only.
Note: If setting 10-6-02 + 10-2-01 or
10-2-02 or 10-2-03 are set at the
same time, then setting 10-2-01,
10-2-02 or 10-2-03 have priority.
Note: If setting 10-6-01 + 10-2-01 or
10-2-02 or 10-2-03 are set at the
same time, then setting for group con-
nection, 10-6-01 has priority and for
individual connection, 10-2-01,
10-2-02 or 10-2-03 have priority.
3 Filter sign display 01
Display
02 Do not display
5 Remote controller thermistor visible by
central control device in group wiring
P1P2
01
no
02 yes
6 Air thermistor selection in group wiring
P1P2
01
return air thermistor (indi-
vidual units)
02 Thermistor designated by
fieldsetting 20-2
7 Absence delay detecting time (pres-
ence sensor)
01
30 minutes
02 60 minutes
8 Compensation air sensor heating 01
add 2°C to measurement
air sensor
02 measurement air sensor
