ESIE15-11A | Part 3. Field settings 3. Wired remote controller BRC1D51/52
23/09/16 Page 29
VRV4 indoor units
1b 0 user permission level (BRC1D) 01 level 2 available: on/off, temperature selec-
tion, delay, min/max operation,
fanspeed, swingflap direction
02 level 3 available: on/off, temperature selec-
tion, fanspeed
1 setback function 01
not available For setback function: After activation
in mode 1b-1, push both buttons
together to activate the function.
On the display the symbol will be visi-
ble.
Function can only be activated when
unit is off.
02 available
2 use of remocon sensor for 'limited'
and 'setback' function
01
active
02 not active
3 Start 'setback' - function 05 5°C
06 6°C
07 7°C
08 8°C
09 9°C
10
10°C
11 11°C
12 12°C
13 13°C
14 14°C
15 15°C
4 Stop 'setback' - function 01
1K
02 2K
03 3K
04 4K
05 5K
5 Usage of 'limited' function in combina-
tion with centralised control
01
not available ‘limited’ function = additional mode to
permit keeping the temperature
between a minimum and maximum
value.
02 available
