Compressor
Distributor
Liquid receiver
Flare connection
A Field piping (liquid: Ø9.5 flare connection)
B Field piping (gas: Ø15.9 flare connection)
Heating
Cooling
12.4 Wiring diagram: Outdoor unit
The wiring diagram is delivered with the unit, located at the inside of
the service cover.
(1) Connection diagram
English Translation
Connection diagram Connection diagram
Only for *** Only for ***
See note *** See note ***
Outdoor Outdoor
Indoor Indoor
Upper Upper
Lower Lower
Fan Fan
ON ON
OFF OFF
(2) Layout
English Translation
Layout Layout
Front Front
Back Back
Position of compressor terminal Position of compressor terminal
(3) Notes
English Translation
Notes Notes
Connection
X1M Indoor/outdoor communication
Earth wiring
Field supply
1
Several wiring possibilities
Protective earth
Field wire
Wiring depending on model
Option
Switch box
PCB
NOTES:
1 Refer to the wiring diagram sticker (on the back of the front
plate) for how to use the BS1~BS3 and DS1 switches.
2 When operating, do not short-circuit protective devices S1PH
S1PLand Q1E.
3 Refer to the combination table and the option manual for how
to connect the wiring to X6A, X28A and X77A.
4 Colours: BLK: black, RED: red, BLU: blue, WHT: white, GRN:
green
(4) Legend
English Translation
Legend Legend
Field supply Field supply
Optional Optional
Part n° Part n°
Description Description
A1P Printed circuit board (main)
A2P Printed circuit board (noise filter)
BS1~BS3 (A1P) Push button switch
C1~C5 (A1P) (Y1
only)
Capacitor
DS1 (A1P) Dipswitch
E1H Bottom plate heater (option)
F*U Fuse
HAP (A1P) Light-emitting diode (service monitor is
green)
K1M, K3M (A1P) (Y1
only)
Magnetic contactor
K1R (A1P) Magnetic relay (Y1S)
K2R (A1P) Magnetic relay (Y2S)
K4R (A1P) Magnetic relay (E1H)
K10R, K13R~K15R
(A1P)
Magnetic relay
K11M (A1P) (V1
only)
Magnetic contactor
L1R (Y1 only) Reactor
M1C Compressor motor
M1F~M2F Fan motor
PFC (A1P) (V1 only) Power factor correction
PS (A1P) Switching power supply
Q1DI Earth leakage circuit breaker (30mA)
Q1E Overload protection
R1~R8 (A1P) (Y1
only)
Resistor
R1T Thermistor (air)
R2T Thermistor (discharge)
R3T Thermistor (suction)
R4T Thermistor (heat exchanger)
R5T Thermistor (heat exchanger middle)
R6T Thermistor (liquid)
R7T Thermistor (fin)
R8 (A1P) (V1 only) Resistor
RC (A1P) (Y1 only) Signal receiver unit
S1PH High pressure switch
S1PL Low pressure switch
SEG1~SEG3 7-segment display
