Specifications SiBE18-821_C
22 Specifications
Ceiling Mounted Cassette Type
50 Hz, 230 V
Note:
★
1 ( ) : dimension including control box
Model
FFQ25B8V1B FFQ35B8V1B
Cooling Heating Cooling Heating
Rated Capacity 2.5 kW Class 3.5 kW Class
Decoration
Panel
Color White White
Dimensions (H × W × D) mm 55 × 700 × 700 55 × 700 × 700
Airflow Rates
m³/min
(cfm)
H 9.0 (318) 9.0 (318) 10.0 (353) 10.0 (353)
M
————
L 6.5 (230) 6.5 (230) 6.5 (230) 6.5 (230)
SL
————
Fan
Type Turbo Fan Turbo Fan
Motor Output W 55 55
Speed Steps 2 Steps 2 Steps
Air Direction Control Horizontal, Downward Horizontal, Downward
Air Filter
——
Running Current (Rated) A 0.37 0.32 0.40 0.36
Power Consumption (Rated) W 73 64 84 76
Power Factor (Rated) % 85.8 87.0 91.3 91.8
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D)
★
1 mm 260 (286) × 575 × 575 260 (286) × 575 × 575
Packaged Dimensions (H × W × D) mm 370 × 687 × 674 370 × 687 × 674
Weight (Mass) kg 17.5 17.5
Gross Weight (Gross Mass) kg 21 21
Operation
Sound
H / L dBA 29.5 / 24.5 32.0 / 25.0
Sound Power dBA 46.5 49.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm VP20 (O.D
φ
26 / I.D
φ
20) VP20 (O.D
φ
26 / I.D
φ
20)
Drawing No. 3D060405 3D060407
Model
FFQ50B8V1B FFQ60B8V1B
Cooling Heating Cooling Heating
Rated Capacity 5.0 kW Class 6.0 kW Class
Decoration
Panel
Color White White
Dimensions (H × W × D) mm 55 × 700 × 700 55 × 700 × 700
Airflow Rates
m³/min
(cfm)
H 12.0 (424) 12.0 (424) 15.0 (530) 15.0 (530)
M
————
L 8.0 (283) 8.0 (283) 10.0 (353) 10.0 (353)
SL
————
Fan
Type Turbo Fan Turbo Fan
Motor Output W 55 55
Speed Steps 2 Steps 2 Steps
Air Direction Control Horizontal, Downward Horizontal, Downward
Air Filter
——
Running Current (Rated) A 0.49 0.45 0.61 0.56
Power Consumption (Rated) W 97 89 120 111
Power Factor (Rated) % 86.1 86.0 85.5 86.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D)
★
1 mm 260 (286) × 575 × 575 260 (286) × 575 × 575
Packaged Dimensions (H × W × D) mm 370 × 687 × 674 370 × 687 × 674
Weight (Mass) kg 17.5 17.5
Gross Weight (Gross Mass) kg 21 21
Operation
Sound
H / L dBA 36.0 / 27.0 41.0 / 32.0 41.0 / 32.0
Sound Power dBA 53.0 58.0
—
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
12.7
φ
12.7
Drain mm VP20 (O.D
φ
26 / I.D
φ
20) VP20 (O.D
φ
26 / I.D
φ
20)
Drawing No. 3D060409 3D040436
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
