Device Description
27
3.3 Technical Data
1)
Stem remains in last position
2)
Stem extends
AMV210 AMV213 AME210 AME213
Safety function
2)
-yes-yes
Stroke mm 15
Positioning time s/mm 12
Positioning force N 300
Voltage supply V 230 V
+10 % -15 %, 50/
60 Hz
24 V +10 % -15 %,
50/60 Hz
Power consumption VA 8
Input signal Three-position
step signal
230 V, 50/60 Hz
0(4)–20 mA
0(2)–10 V
Output signal – 0(2)–10 V
Behavior in case of a
drop-out
1) 2) 1) 2)
Type of protection
acc. to EN 60529
IP 54 if installed in a vertical upright position,
other installation positions: IP 52
Safety class DIN VDE 0106 II
Ambient operation
temperature
°C -10 to +50
Ambient storage and
transportation
temperature
° C -10 to +70
End position switch-off Switch-off dependent on torque
Additional Equipment (cannot be added later)
End switches (2 pieces)
(only design AMV210, 213)
voltage-free, two-way switch, max. 250 V AC or
DC, 2 A resistive load, 1 A inductive load
