13MG.30.A7.02 - VLT
®
is a registered Danfoss trademark
Mains: 380/400/415 V
Typical shaft Constant output Constant output
VLT
®
type output current I
VLT,N
power at 415 V
[kW] [A] [kVA]
3002 1.1 2.8 2.0
3003 1.5 4.1 2.9
3004 2.2 5.6 4.0
3006 4.0 5.5 10.0 13.0 7.2 9.3
3008 5.5 7.5 13.0 16.0 9.3 11.5
3011 7.5 11 16.0 24.0 11.5 17.3
3016 11 15 24.0 32.0 17.3 23.0
3022 15 22 32.0 44.0 23.0 31.6
3032 22 30 44.0 61.0 31.6 43.8
3042 30 37 61.0 73.0 43.8 52.5
3052 37 45 73.0 88.0 52.3 63.3
3060 45 55 86.0 105 61.8 75.5
3075 55 75 105 139 75.5 99.9
3100 75 90 139 168 99.9 120
3125 90 110 168 205 120 147
3150 110 132 205 243 147 174
3200 132 160 243 302 174 217
3250 160 200 302 368 217 264
CT VT CT VT
CT: Constant torque
VT: Variable torque (quadratic load)
CT VT CT VT
CT VT
CT: Constant torque
VT: Variable torque (quadratic load)
Sizing
Typical shaft Constant output Constant output
VLT
®
type output current I
VLT,N
power at 500 V
[kW] [A] [kVA]
3002 1.1 2.6 2.3
3003 1.5 3.4 2.9
3004 2.2 4.8 4.1
3006 4.0 8.2 7.1
3008 5.5 11.1 9.6
3011 7.5 11 14.5 21.7 12.6 18.8
3016 11 15 21.7 27.9 18.8 24.1
3022 15 22 27.9 41.4 24.1 36.0
3032 22 30 41.4 54.0 36.0 46.8
3042 30 37 54.0 65.0 46.8 56.3
3052 37 45 65.0 78.0 56.3 67.5
3060 55 75 77.0 96.0 66.7 83.1
3075 75 90 96.0 124 83.1 107
3100 90 110 124 156 107 135
3125 110 132 156 180 135 156
3150 132 160 180 240 156 208
3200 160 200 240 302 208 262
3250 200 250 302 361 262 313
CT VT
Mains: 440/460/500 V
