3.10 Main Menu - Profibus - Group 9
3.10.1 9-** Profibus
Parameter group for all Profibus-specific parameters.
9-15 PCD Write Configuration
Array [10]
Option: Function:
Select the parameters to be assigned to PCD 3 to 10 of the messages. The number of available PCDs
depends on the message type. The values in PCD 3 to 10 will then be written to the selected pa-
rameters as data values. Alternatively, specify a standard Profibus message in par.9-22
Telegram
Selection
.
[0] * None
[302] Minimum Reference
[303] Maximum Reference
[341] Ramp 1 Ramp-up Time
[342] Ramp 1 Ramp-down Time
[351] Ramp 2 Ramp-up Time
[352] Ramp 2 Ramp-down Time
[380] Jog Ramp Time
[381] Quick Stop Ramp Time
[411] Motor Speed Low Limit [RPM]
[413] Motor Speed High Limit [RPM]
[416] Torque Limit Motor Mode
[417] Torque Limit Generator Mode
[590] Digital & Relay Bus Control
[593] Pulse Out #27 Bus Control
[595] Pulse Out #29 Bus Control
[597] Pulse Out #X30/6 Bus Control
[653] Terminal 42 Output Bus Control
[663] Terminal X30/8 Output Bus Control
[890] Bus Jog 1 Speed
[891] Bus Jog 2 Speed
[894] Bus Feedback 1
[895] Bus Feedback 2
[896] Bus Feedback 3
[1680] Fieldbus CTW 1
[1682] Fieldbus REF 1
[2013] Minimum Reference/Feedb.
[2014] Maximum Reference/Feedb.
[2643] Terminal X42/7 Output Bus Control
[2653] Terminal X42/9 Output Bus Control
[2663] Terminal X42/11 Output Bus Control
