[2158] Ext. 3 Feedback [Unit] The value of the feedback signal for extended Closed-loop Controller 3
[2159] Ext. 3 Output [%] The value of the output from extended Closed-loop Controller 3
[2230] No-Flow Power The calculated No-Flow Power for the actual operating speed
[2316] Maintenance Text
[2580] Cascade Status Status for the operation of the cascade controller
[2581] Pump Status Status for the operation of each individual pump controlled by the cascade controller
[3110] Bypass Status Word
[3111] Bypass Running Hours
NOTE!
Consult the
VLT HVAC Drive Programming Guide, MG.11.CX.YY for detailed information.
0-21 Display Line 1.2 Small
Option: Function:
Select a variable for display in line 1, middle position.
[1614] * Motor Current
The options are the same as those listed in par.0-20
Display Line 1.1 Small .
0-22 Display Line 1.3 Small
Option: Function:
Select a variable for display in line 1, right position.
[1610] * Power [kW]
The options are the same as those listed in par.0-20
Display Line 1.1 Small .
0-23 Display Line 2 Large
Option: Function:
Select a variable for display in line 2.
[1613] * Frequency
The options are the same as those listed in par.0-20
Display Line 1.1 Small .
0-24 Display Line 3 Large
Option: Function:
[1502] * kWh Counter Select a variable for display in line 3. The options are the same as listed for par. 0-20.
0-25 My Personal Menu
Array [20]
Range: Function:
0 N/A* [0 - 9999 N/A] Define up to 20 parameters to appear in the Q1 Personal Menu, accessible via the [Quick Menu]
key on the LCP. The parameters will be displayed in the Q1 Personal Menu in the order they are
programmed into this array parameter. Delete parameters by setting the value to ‘0000’.
For example, this can be used to provide quick, simple access to just one or up to 20 parameters
which require changing on a regular basis (e.g., for plant maintenance reasons) or by an OEM to
enable simple commissioning of their equipment.
3 Parameter Description VLT
®
HVAC Drive Programming Guide
3-10 MG.11.C6.22 - VLT
®
is a registered Danfoss trademark
