Page 25
Site requirements
Operating environment
• Relative humidity: 20% to 80% non-condensing
• Temperature: 60° F to 95° F (15° C to 35° C)
Electrical requirements
• The external power supply is rated at 100-240 VAC, 50-60 Hz,
1.8 amp. (It adjusts to any power within this range.)
• Single phase, 3-wire, grounded receptacle only.
Physical requirements
• The printer weighs less than 11.5 pounds (5.3 kg). The weight
depends on the supplies and options installed.
• Printer dimensions are 21.5 inches (546 mm) long and 7.8
inches (198 mm) wide. The 100-card input hopper is 9.5 inches
(241 mm) high and the 200-card hopper is 11.9 inches (302 mm)
high.
• The clearance required 1 inch (25 mm) at the back, 2 inches (5
cm) on the left side, and 10.5 inches (267 mm) above the printer
latch to open the cover.
Do not use the printer in a dirty environment. Do not use the printer
in a closed compartment. Do not block air flow around the printer.
9.5”
11.9”
10.5” (for cover)
7.8”
2”
1”
21.5”
