GENERAL FEATURES
3
1
1.3 AVAILABLE MODELS
The DS2100 scanner is available in versions that differ in regard to the following
parameters:
• Resolution
• Interface module and termination of the cable
• Linear or raster models
• Performance
The following models are therefore available:
DS2100 - X X X X
Optical Resolution
1 = Standard Resolution
2 = High Resolution
Serial Communication Interface
0 = RS232 main + RS232 aux 25-pin connector
1 = RS485 main + RS232 aux 25-pin connector
3 = RS232 main 9-pin connector
Performance
0 = Standard
4 = Testarossa™
Linear/Raster
0 = Linear
1 = Raster
The following tables display each version’s reading performance.
Version Max Code Resolution Speed
mm (mils) scans/s
1XX0 0.20 (8) 350
1XX4 0.20 (8) 800
2XX0 0.15 (6) 350
2XX4 0.12 (5) 600
Version Reading Distance
1XX0 40 mm (1.6 in) - 300 mm (11.8 in) on 0.50 mm (20 mils) codes
1XX4 45 mm (1.8 in) - 300 mm (11.8 in) on 0.50 mm (20 mils) codes
2XX0 30 mm (1.2 in) - 90 mm (3.5 in) on 0.30 mm (12 mils) codes
2XX4 45 mm (1.8 in) - 100 mm (3.9 in) on 0.20 mm (8 mils) codes
See reading diagrams in par. 3.4 for further details.
