Datalogic QuickScan QD2590 Quick Reference Guide

LED and Beeper Indications
30 QUICKSCAN™ QD2590
LED AND BEEPER INDICATIONS
The imager’s beeper sounds and its illumination flashes or
changes color to indicate various functions or errors on
the reader. A “Green Spot” also lights to indicate a good
read. The tables below list these indications. Reference
the PRG for a more detailed list.
INDICATION LED BEEPER
Power-up
Upper LED flashes/
blinks on power-up,
however, this may be
too rapid to view.
With a USB interface,
the LED blinks until
enumeration with
the host is
completed.
Imager beeps four
times at highest
frequency and volume
upon power-up.
Good Read
Upper green LED
comes on for
programmed time
(default).
LED behavior for this
indication is
configurable using
Aladdin utility.
One beep at current
frequency, volume,
mono/bi-tonal setting
upon a successful label
scan. It is also possible
to upload custom
jingles with Aladdin.
ROM Failure
200ms on / 200ms off
Imager sounds one
error beep at highest
volume for 200 ms.
Limited Scanning
Label Read
N/A
Imager 'chirps' six
times at the highest
frequency and current
volume.
Reader Disabled
The LED blinks
continuously 100ms
on / 900 ms off
N/A

Datalogic QuickScan QD2590 Specifications

General

Type	Handheld bar code reader
Sensor type	-
Scanner type	1D/2D
Scanner resolution	0.17 mm
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 65 °
Light levels (direct sunlight)	0 - 100000 lx
Linear (1D) barcodes supported	CPC Binary, Codabar, Codabar 125, Code 11, Code 128, Code 128A, Code 128B, Code 128C, Code 25 (IR 2 of 5), Code 25 (non-IR 2 of 5), Code 3 of 9, Code 32, Code 39, Code 93, DUN 14, DataBar14, Discrete 2 of 5, EAN 128, EAN 2, EAN 5, EAN-13, EAN-8, Facing Identification Mark, GS1 DataBar, GS1 DataBar Expanded, GS1 DataBar Omnidirectional, GS1 Databar Limited, GS1-128 (UCC/EAN-128), HIBC, IATA, ISBN, ISSN, ITF-14, ITF-6, Industrial 2 of 5, Intelligent Mail, Interleaved 2 of 5, JAN, Latent image, MSI, Matrix 2 of 5, PDF417, PLANET, POSTNET, Pharmacode, Plessey, PostBar, RM4SCC / KIX, S-Code, Telepen, Trioptic, U.P.C., UPC-A, UPC-E
Optical sensor resolution (W x H)	1280 x 800 pixels
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Dot Code A, MaxiCode, Micro QR Code, QR Code
Cable length	2 m
Standard interfaces	USB
Connectivity technology	Wired
Product color	Black
Image formats supported	BMP, JPEG, TIFF
International Protection (IP) code	IP52
Input voltage	5 V
Power consumption	450 mA
Cables included	USB Type-C
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Sustainability certificates	RoHS
Material	Polyvinyl chloride (PVC)
Connector 1	USB C
Product type	USB cable
Connector gender	Male/Male
Brand compatibility	Datalogic
Connector 1 form factor	Straight
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	126 mm
Width	148 mm
Height	68 mm
Weight	145 g
