14
Chapter 1 PPI/DGL SETUP Menu
Euro Character
Allows the operator to select the position of the Euro character in the code
page.
Control Codes
Allows the operator to change the prefix of the software commands
interpreted by the printer.
When ‘User-Defined’ is selected, 5 additional sub-menus are inserted in the
menu tree. These sub-menus allow the user to set a value for each of the
control codes. The default ‘User-Defined’ values are shown in the table
above.
Feedback Chars
When enabled, the printer returns a Hex 1E [RS] after each label successfully
prints, and Hex 1F [US] after each batch of labels is printed.
For invalid characters, the printer responds with Hex 07 [BEL].
• Enabled. Feedback characters are sent to the host.
• Disabled. No feedback characters are sent.
The default is Disabled.
Default Module
Sets the default module used to store files when no module or default module
is specified in the command. (See Chapter 3 for further details.)
.
• RAM.
• Flash.
The default is RAM.
Units of Measure
Sets the printer to interpret measurements as Imperial or Metric values.
• Imperial.
• Metric.
The default is Imperial.
NOTE: <STX>n and <STX>m commands override this setting, and stay in
effect until the printer is take Offline and back Online.
SOH STX CR ESC ‘Count By’
Standard
0x01 0x02 0x0D 0x1B 0x5E
Alternate
0x5E 0x7E 0x0D 0x1B 0x40
Alternate 2
0x5E 0x7E 0x7C 0x1B 0x40
User-Defined
0x01 0x02 0x0D 0x1B 0x5E
