Dell 5600R OL HV-US 5600W User Manual

15
Installation
|
UPS Rear Panels
This section shows the rear panels of the Dell Online Rack models.
UPS
Communication
Bay
Input Terminal
Block
USB Port
Four IEC 320-C19 Receptacles
(Load Segment 1)
REPO
Ports
RS-232
Port
Two NEMA L6-30R Receptacles
(Load Segment 2)
EBM
Connector
Output Circuit Breaker
Ground
Screw
Two Output Circuit Breakers
Figure 4. 5600W, 208V Rear Panel
Six IEC 320-C13
Receptacles
(Load Segment 2)
REPO
Ports
Four IEC 320-C19 Receptacles
(Load Segment 1)
EBM
Connector
Two Output Circuit Breakers
UPS
Communication
Bay
USB Port
RS-232
Port
Input Terminal
Block
Ground
Screw
Output Circuit
Breaker
Figure 5. 5600W, 230V Rear Panel
