Dell C2422HE User Manual

52 | Setting up the monitor
Connecting the monitor for DPBS for the first time
Initial monitor power state(OFF)
Initial system power state(OFF)
USB Type-C
USB Type-C
For the first time setting up the DPBS function, please follow below steps:
1. Make sure both the PC and monitor is OFF.
2. Connect the USB Type-C cable from the PC to the monitor.
3. Press the monitor power button to turn ON the monitor.
4. Both the monitor and PC will turn ON momentarily. Wait for a while (approximately 6
seconds) and both the PC and monitor will turn OFF.
5. Press either the monitor power button or PC power button, both the PC and
monitor will turn ON. The PC system power state is in sync with the monitor power
button.
NOTE: When the monitor and PC are both at power OFF state at first time,
it is recommended that you turn ON the monitor first, then connect the USB
Type-C cable from the PC to the monitor.
NOTE: You can power the OptiPlex 7090/3090 Ultra platform using its DC
adaptor jack. Alternatively, you can power the OptiPlex 7090/3090 Ultra
platform using the monitor’s USB-C cable via Power Delivery (PD); please set
USB-C Charging to On in Off Mode.

Dell C2422HE Specifications

General

Pixel pitch	0.2745 x 0.2745 mm
Screen shape	Flat
Pixel density	92.56 ppi
Response time	8 ms
Backlight type	LED
Display diagonal	23.8 \
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	56 - 76 Hz
Maximum refresh rate	60 Hz
Response time (fast)	6 ms
Horizontal scan range	30 - 83 kHz
Supported video modes	480i, 480p, 576i, 720p, 1080i, 1080p
Viewable size, vertical	296.46 mm
sRGB coverage (typical)	99 %
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display diagonal (metric)	60.47 cm
Viewable size, horizontal	527.04 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDMI version	1.4
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.2
Headphone connectivity	3.5 mm
USB upstream port type	USB Type-C
USB Power Delivery up to	90 W
USB Type-A downstream ports quantity	3
Number of USB Type-C upstream ports quantity	2
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 21 °
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	195 W
Power consumption (standby)	0.2 W
Power consumption (typical)	14.2 W
Megapixel	5 MP
RMS rated power	10 W
Cables included	AC, DisplayPort, USB Type-A to USB Type-B, USB Type-C to USB Type-C
DisplayPort cable length	1.8 m
Package weight	8820 g
Doesn't contain	PVC/BFR
Sustainability certificates	ENERGY STAR, RoHS
Feet color	Silver
Product color	Black, Silver
Front bezel color	Black
Heavy metals free	Hg (mercury)
Market positioning	Home
Operating altitude	0 - 5000 m
Non-operating altitude	5000 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Harmonized System (HS) code	85285210

Weight and Dimensions

Bezel width (top)	5.8 mm
Depth (with stand)	185 mm
Width (with stand)	538.64 mm
Height (with stand)	544.08 mm
Weight (with stand)	6120 g
Bezel width (bottom)	50.89 mm
Depth (without stand)	51.24 mm
Height (without stand)	383.15 mm
Weight (without stand)	4330 g
