8 | About your monitor
USB 3.2 Gen1 Type-A to Type-B upstream
cable
USB Type-C cable (C to C)
• Quick Setup Guide
• Safety, Environmental, and Regulatory
Information
Product features
The Dell C2422HE/C2722DE/C3422WE monitor has an active matrix, Thin-Film
Transistor (TFT), Liquid Crystal Display (LCD), and LED backlight. The monitor features
include:
• C2422HE: 60.47 cm (23.8 in.) active area display (Measured diagonally) 1920 x
1080 (16:9) resolution, plus full-screen support for lower resolutions.
• C2722DE: 68.47 cm (27.0 in.) active area display (Measured diagonally) 2560 x
1440 (16:9) resolution, plus full-screen support for lower resolutions.
• C3422WE: 86.71 cm (34.14 in.) active area display (Measured diagonally) 3440 x
1440 (21:9) resolution, plus full-screen support for lower resolutions.
• Wide viewing angles with 99% sRGB color.
• C2422HE/C2722DE:Tilt, swivel, pivot and vertical extension adjustment
capabilities.
• C3422WE:Tilt, swivel and vertical extension adjustment capabilities.
• Built-in speakers (2 x 5 W).
• Removable pedestal stand and Video Electronics Standards Association (VESA™)
100 mm mounting holes for flexible mounting solutions.
• Ultra-thin bezel minimizes the bezel gap during multi-monitor usage, enabling
easier set up with an elegant viewing experience.
• Extensive digital connectivity with DP helps future-proof your monitor.
• Single USB Type-C to supply power to compatible notebook while receiving video
signal.
• USB-C and RJ45 ports enable a single-cable, network-connected experience.
• Plug and play capability if supported by your computer.
• On-Screen Display (OSD) adjustments for ease of set-up and screen
optimization.

Dell C2422HE Specifications

General

Pixel pitch	0.2745 x 0.2745 mm
Screen shape	Flat
Pixel density	92.56 ppi
Response time	8 ms
Backlight type	LED
Display diagonal	23.8 \
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	56 - 76 Hz
Maximum refresh rate	60 Hz
Response time (fast)	6 ms
Horizontal scan range	30 - 83 kHz
Supported video modes	480i, 480p, 576i, 720p, 1080i, 1080p
Viewable size, vertical	296.46 mm
sRGB coverage (typical)	99 %
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display diagonal (metric)	60.47 cm
Viewable size, horizontal	527.04 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDMI version	1.4
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.2
Headphone connectivity	3.5 mm
USB upstream port type	USB Type-C
USB Power Delivery up to	90 W
USB Type-A downstream ports quantity	3
Number of USB Type-C upstream ports quantity	2
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 21 °
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	195 W
Power consumption (standby)	0.2 W
Power consumption (typical)	14.2 W
Megapixel	5 MP
RMS rated power	10 W
Cables included	AC, DisplayPort, USB Type-A to USB Type-B, USB Type-C to USB Type-C
DisplayPort cable length	1.8 m
Package weight	8820 g
Doesn't contain	PVC/BFR
Sustainability certificates	ENERGY STAR, RoHS
Feet color	Silver
Product color	Black, Silver
Front bezel color	Black
Heavy metals free	Hg (mercury)
Market positioning	Home
Operating altitude	0 - 5000 m
Non-operating altitude	5000 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Harmonized System (HS) code	85285210

Weight and Dimensions

Bezel width (top)	5.8 mm
Depth (with stand)	185 mm
Width (with stand)	538.64 mm
Height (with stand)	544.08 mm
Weight (with stand)	6120 g
Bezel width (bottom)	50.89 mm
Depth (without stand)	51.24 mm
Height (without stand)	383.15 mm
Weight (without stand)	4330 g
