Dell C7520QT User Manual

12 | About Your Display
Display Specifications
Screen type Active matrix - TFT LCD
Panel Type In-plane switching Technology
Aspect ratio 16:9
Viewable image dimensions
Diagonal 189.273 cm (74.52 inches)
Active Area
Horizontal 1649.664 mm (64.95 inches)
Vertical 927.936 mm (36.53 inches)
Area 1530323.4 mm
2
(2372 inches
2
)
Pixel pitch 0.429 mm x 0.429 mm
Pixel per inch (PPI) 59
Viewing angle
Horizontal 178° (typical)
Vertical 178° (typical)
Panel brightness 350 cd/m² (typical)
Contrast ratio 1200 to 1 (typical)
Display screen coating 9H, Anti-Smudge, Anti-Glare
Response Time 8 ms typical (G to G), 12 ms max. (G to G )
Color depth 1.07 Billon colors
Color gamut NTSC ( 72%)
Connectivity •1 x DP 1.2
•1 x VGA
•3 x HDMI 2.0
•4 x USB 3.0 downstream port
(
1 x USB BC1.2 charging capability at 2A (max)
)
•3 x USB 3.0 upstream port
•1 x Analog 2.0 audio line out (3.5 mm jack)
•1 x Analog 2.0 audio line in (3.5 mm jack)
•1 x RJ-45
•1 x RS232
Border width (edge of display to
active area)
42.75 mm (Top)
42.69 mm (Left/Right)
46.75 mm (Bottom)

Dell C7520QT Specifications

General

Color gamut	72 %
Pixel pitch	0.429 x 0.429 mm
Aspect ratio	16:9
Screen shape	Flat
Response time	8 ms
Backlight type	LED
Display diagonal	74.5 \
Surface hardness	9H
Touch technology	Multi-touch
Touchscreen type	Multi-user
Anti-glare surface	Yes
Display brightness	350 cd/m²
Display technology	LCD
Native refresh rate	60 Hz
Supported video modes	2160p
Viewable size diagonal	1892.7 mm
Contrast ratio (typical)	1200:1
Display number of colors	1.073 billion colors
Number of simultaneous touchpoints	20
Certification	UL
Product color	Black
Panel mounting interface	400 x 400 mm
Placement supported	Horizontal
Ethernet LAN (RJ-45) ports	1
Display viewable area (HxV)	1649.7 x 927.9 mm
Cables included	DisplayPort, HDMI, USB, VGA
DVI port	-
USB version	2.0/3.2 Gen 1 (3.1 Gen 1)
USB hub version	3.2 Gen 1 (3.1 Gen 1)
USB connector type	USB Type-A, USB Type-B
USB ports quantity	7
HDMI ports quantity	3
USB upstream port type	USB Type-B
Height adjustment	No
AC input voltage	100 - 240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	270 W
Power consumption (standby)	0.3 W
Power consumption (typical)	140 W
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12191 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	20 - 80 %
RMS rated power	40 W
Number of speakers	2
Sustainability certificates	RoHS, ENERGY STAR
Harmonized System (HS) code	85285210
Package weight	Weight of the packaged product in gram.

Weight and Dimensions

Depth	78.74 mm
Width	1734.82 mm
Height	1018.54 mm
Weight	64000 g
Display width	1735.02 mm
Display height	1017.44 mm
Depth (without stand)	79.1 mm
Width (without stand)	1735 mm
Height (without stand)	1017.4 mm
Weight (without stand)	76000 g
