52 | Operating the Display
Dell Web Management for Displays
Before accessing the Dell Display Web Management feature, ensure the Ethernet is working
normally.
1 2 3 4 5 6 7
• Ethernet Enable
Touch and hold the touch key 5 on the front panel for 4 seconds to turn on , A network icon
appears and is shown on the center for 4 seconds.
• Ethernet Disable
Touch and hold the touch key 5 on the front panel for 4 seconds to turn off , A network icon
appears and is shown on the center for 4 seconds.
To access the Dell Display Web Management tool you need to set the IP Addresses for your
computer and the display.
1. Press the Menu key on the remote control to display the IP Address of the display, or by
navigating to OSD Menu > Others. By default, the IP Address is 10.0.50.100
Brightness/Contrast
Others
Color
Display
Input Source
Dell 75 Monitor
Auto Adjust
Audio
Menu
Personalize
DCC/CI
On
Display Info
Firmware
M2T103
HDMI CEC
LCD Conditioning
O
O
Reset Others
Factory Reset ENERGY STAR
®
IP Address
10.0.50.100
Service Tag
ABCDEFG

Dell C7520QT Specifications

General

Color gamut	72 %
Pixel pitch	0.429 x 0.429 mm
Aspect ratio	16:9
Screen shape	Flat
Response time	8 ms
Backlight type	LED
Display diagonal	74.5 \
Surface hardness	9H
Touch technology	Multi-touch
Touchscreen type	Multi-user
Anti-glare surface	Yes
Display brightness	350 cd/m²
Display technology	LCD
Native refresh rate	60 Hz
Supported video modes	2160p
Viewable size diagonal	1892.7 mm
Contrast ratio (typical)	1200:1
Display number of colors	1.073 billion colors
Number of simultaneous touchpoints	20
Certification	UL
Product color	Black
Panel mounting interface	400 x 400 mm
Placement supported	Horizontal
Ethernet LAN (RJ-45) ports	1
Display viewable area (HxV)	1649.7 x 927.9 mm
Cables included	DisplayPort, HDMI, USB, VGA
DVI port	-
USB version	2.0/3.2 Gen 1 (3.1 Gen 1)
USB hub version	3.2 Gen 1 (3.1 Gen 1)
USB connector type	USB Type-A, USB Type-B
USB ports quantity	7
HDMI ports quantity	3
USB upstream port type	USB Type-B
Height adjustment	No
AC input voltage	100 - 240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	270 W
Power consumption (standby)	0.3 W
Power consumption (typical)	140 W
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12191 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	20 - 80 %
RMS rated power	40 W
Number of speakers	2
Sustainability certificates	RoHS, ENERGY STAR
Harmonized System (HS) code	85285210
Package weight	Weight of the packaged product in gram.

Weight and Dimensions

Depth	78.74 mm
Width	1734.82 mm
Height	1018.54 mm
Weight	64000 g
Display width	1735.02 mm
Display height	1017.44 mm
Depth (without stand)	79.1 mm
Width (without stand)	1735 mm
Height (without stand)	1017.4 mm
Weight (without stand)	76000 g
