Dell C7520QT User Manual

Setting Up the Display | 31
Remote Control
4. Left
Press to move the selection left in OSD
menu.
5. Down
Press to move the selection down in OSD
menu.
6. Menu
Press to turn on the OSD menu.
7. Brightness -
Press to decrease the Brightness.
8. Volume -
Press to decrease the Volume.
9. MUTE
Press to turn the mute function on/off.
10.Preset Modes
Display information about Preset Modes.
11. Right
Press to move the selection right in OSD
menu.
12. OK
Confirm an entry or selection.
13. Exit
Press to exit the Menu.
14. Brightness +
Press to increase the Brightness.
15. Volume +
Press to increase the Volume.
1. Power On/Off
Switch this display on or off.
2. Input Source
Select input source. Press or button to
select from VGA or DP or HDMI 1 or HDMI 2 or
HDMI 3.
Press button to confirm and exit.
3. Up
Press to move the selection up in OSD menu.

Dell C7520QT Specifications

General

Color gamut	72 %
Pixel pitch	0.429 x 0.429 mm
Aspect ratio	16:9
Screen shape	Flat
Response time	8 ms
Backlight type	LED
Display diagonal	74.5 \
Surface hardness	9H
Touch technology	Multi-touch
Touchscreen type	Multi-user
Anti-glare surface	Yes
Display brightness	350 cd/m²
Display technology	LCD
Native refresh rate	60 Hz
Supported video modes	2160p
Viewable size diagonal	1892.7 mm
Contrast ratio (typical)	1200:1
Display number of colors	1.073 billion colors
Number of simultaneous touchpoints	20
Certification	UL
Product color	Black
Panel mounting interface	400 x 400 mm
Placement supported	Horizontal
Ethernet LAN (RJ-45) ports	1
Display viewable area (HxV)	1649.7 x 927.9 mm
Cables included	DisplayPort, HDMI, USB, VGA
DVI port	-
USB version	2.0/3.2 Gen 1 (3.1 Gen 1)
USB hub version	3.2 Gen 1 (3.1 Gen 1)
USB connector type	USB Type-A, USB Type-B
USB ports quantity	7
HDMI ports quantity	3
USB upstream port type	USB Type-B
Height adjustment	No
AC input voltage	100 - 240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	270 W
Power consumption (standby)	0.3 W
Power consumption (typical)	140 W
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12191 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	20 - 80 %
RMS rated power	40 W
Number of speakers	2
Sustainability certificates	RoHS, ENERGY STAR
Harmonized System (HS) code	85285210
Package weight	Weight of the packaged product in gram.

Weight and Dimensions

Depth	78.74 mm
Width	1734.82 mm
Height	1018.54 mm
Weight	64000 g
Display width	1735.02 mm
Display height	1017.44 mm
Depth (without stand)	79.1 mm
Width (without stand)	1735 mm
Height (without stand)	1017.4 mm
Weight (without stand)	76000 g
