Dell E157FPc User Manual

15" LCD Color Monitor Dell E157FPc
7
C
Auto Adjust
Use this button to activate automatic setup and adjustment. The following
dialog will appear on screen as the monitor self-adjusts to the current
input:
Auto Adjust In Progress
Auto Adjustment button allows the monitor to self-adjust to the
incoming video signal. After using 'Auto Adjustment', you can further tune
your monitor by using the 'Pixel Clock' and 'Phase' controls in the OSD.
Note: Auto Adjust will not occur if you press the button while
there are no active video input signals, or attached cables.
D
Power Button & Indicator
The green LED indicates the monitor is on and fully functional. An amber
LED indicates DPMS power save mode.
The Power button turns the monitor on and off.
3.3 On Screen Menu/Display (OSD)
Direct-Access Functions
Function Adjustment Method
Auto adjustment
Use this button to activate automatic setup and adjustment. The
following dialog will appear on screen as the monitor self-adjusts
to the current input:
Auto Adjust In Progress
Auto Adjustment button allows the monitor to self-adjust to
the incoming video signal. After using 'Auto Adjustment', you
can further tune your monitor by using the 'Pixel Clock' and
'Phase' controls in the OSD.
Note: Auto Adjust will not occur if you press the button
while there are no active video input signals, or attached
cables.
Brightness / Contrast
With the menu off, push
button to display the 'Brightness'
and 'Contrast' adjustment menu. The 'Brightness' function
adjusts the luminance of the flat panel. Adjust 'Brightness' first,
then adjust 'Contrast' only if further adjustment is necessary."+"
increase 'brightness'; " - "decrease 'brightness'
The 'Contrast' function adjusts the degree of difference between
darkness and lightness on the display screen.
"+" increase the 'contrast'
"-" decrease the 'contrast'
