17" LCD Color Monitor Dell E178FPC
5
1. Monitor Specifications
Screen type Active matrix - TFT LCD
Panel Type
M170EG01 VD00 ZBD DELL AUO
Size
17 inches (17-inch diagonal viewable image size)
Pixel pitch
0.264 mm
Viewable angle
Viewing angle 160 (vertical) typ, 160 (horizontal) typ
LCD Panel
Response time 5ms typical(Black to White)
Video R, G, B Analog Interface, DVI digital Interface
Separate Sync H/V TTL
H-Frequency 30 kHz to 81 kHz (automatic)
Input
V-Frequency 56 Hz to 76 Hz (automatic)
Display Colors 16.7M
Dot Clock 135MHz (Max.)
Max. Resolution
1280 x 1024 at 75 Hz
Plug & Play VESA DDC
ON Mode 34 W (typical)
EPA ENERGY
STAR
®
OFF Mode <1W
Input Connector
15-pin D-subminiature, blue connector
Maximum Screen Size
Horizontal : 337.9 mm (13.3 inches)
Vertical: 270.3 mm (10.6 inches)
Power Source
100 to 240 VAC / 50-60 Hz / 1.5A (RMS) Max.
Environmental
Considerations
Operating Temp: 5° to 35°C
Operating Humidity: 10% to 80%
Storage Temp.: -20° to 60°C
Weight
Weight with packaging: 12.9 lbs (5.85kg)
Weight with stand assembly and cables: 10.2 lbs (4.63 kg)
Weight without stand assembly: 8. 1 lbs (3.69 kg)
