19" LCD Color Monitor Dell E1909Wc
7
3. Operation instructions
3.1 Control Buttons
Use the buttons on the front of the monitor to adjust the image settings.
Front panel Button Description
A
Menu
Use the MENU button to launch the on-screen display (OSD) and select the OSD
Menu.
B
Brightness&Con
trast /Adjust UP
Use this button to directly access the "Brightness/Contrast" menu or to increase the
values of the selected menu option.
C
Automatic
Adjust /Adjust
Down
Use Auto Adjust to activate automatic setup/adjustment or to decrease the values of
the selected menu option. The following dialog appears on a black screen as the
monitor self-adjusts to the current input:
Auto Adjustment allows the monitor to self-adjust to the incoming video signal. After
using Auto Adjustment, you can further tune your monitor by using the Pixel Clock
(Coarse) and Phase (Fine) controls under Image Settings.
D
Input Source
Select/Select
Use this button to select the input source or select an OSD menu option. Use the
Input source button to select one of the two different video signals that may be
connected to your monitor:
• VGA input
