Dell E198FP User Manual

Vertical
301.1 mm (11.8 inches)
Pixel pitch
0.294 mm
Viewing angle
160¢X (Vertical) typical, 160¢X (Horizontal) typical
Luminance output
300 cd/m ²(typ)
Contrast ratio
800:1 (typ)
Faceplate coating
Antiglare with hard-coating 3H
Backlight
4 CCFLs backlight
Response Time
5ms typical (Black to White)
Resolution

Horizontal scan range
30 kHz to 81 kHz (automatic)
Vertical scan range
56Hzto76Hz
Optimal preset resolution
1280 x 1024 at 60 Hz
Highest preset resolution
1280 x 1024 at 75 Hz
Preset Display Modes
The following table lists the preset modes for which Dell guarantees image size and centering:
Display Mode
Horizontal
Frequency (kHz)
Vertical Frequency
(Hz)
Pixel Clock
(MHz)
Sync Polarity
(Horizontal/Vertical)
VGA, 720 x 400
31.5
70.1
28.3
-/+
VGA, 640 x 480
31.5
59.9
25.2
-/-
VESA, 640 x 480
37.5
75.0
31.5
-/-
VESA, 800 x 600
37.9
60.3
40.0
+/+
VESA, 800 x 600
46.9
75.0
49.5
+/+
VESA, 1024 x 768
48.4
60.0
65.0
-/-
VESA, 1024 x 768
60.0
75.0
78.8
+/+
VESA, 1152 x 864
67.5
75.0
108.0
+/+
VESA, 1280 x 1024
64.0
60.0
108.0
+/+
VESA, 1280 x 1024
80.0
75.0
135.0
+/+
Electrical
The following table lists the electrical specification:
Video input signals
Analog RGB: 0.7 Volts +/-5%,75ohminputimpedance
Synchronization input signals
separate horizontal and vertical,
3.3V Cmos or 5V TTL level, positive or negative sync.
AC input voltage / frequency / current
100 to 240 VAC / 50 or 60 Hz + 3 Hz / 1.0 A (Max.)
Inrush current
120V: 40A (Max.)
240V: 80A (Max.)
Physical Characteristics
The following table lists the physical characteristics:
Signal cable type
D-sub: Detachable, Analog, 15pin, shipped attached to the
monitor
Dimensions (with stand):

Height
410.9 mm (16.17 inches)
Width
412.7 mm (16.2 inches)
Depth
144.4 mm (5.7 inches)
Weight

Monitor (Stand and Head)
4.83kg(10.7 lb)
Monitor Flat panel only (VESA Mode)
3.81 kg (8.4 lb)
Weight with packaging
6.32 kg (13.9 lb)
Environmental
The following table lists the environmental limitation:
