Dell E2010H User Manual

Back to Contents Page

Operating the Monitor
Dell™E2010H/E2210H/E2310H Flat Panel Monitor User's Guide
Using the Front Panel Controls
Using the On-Screen Display (OSD) Menu
Setting the Maximum Resolution
Using the Dell Soundbar (Optional)
Using the Tilt

Power On the Monitor
Press the button to turn on the monitor.

Using the Front Panel Controls
Usethekeysonthefrontofthemonitortoadjusttheimagesettings.

Front panel Key
Description
A
Preset Modes

Use the Preset modes key to choose from a list of preset color modes. See Using the OSD Menu.
B
Brightness / Contrast
Use the Brightness / Contrast key to adjust the brightness and contrast.
C
Menu

Use the Menu key to access the Menu.
D
Exit

Use the Exit key to exit the Menu.
Downloaded from ManualMonitor.com Manuals

Dell E2010H Specifications

General

3D	Yes
HD type	-
Panel type	TN
Pixel pitch	0.277 x 0.277 mm
Aspect ratio	16:9
Display diagonal	20 \
Display resolution	1600 x 900 pixels
Display technology	LED
Viewable size, vertical	249 mm
Viewing angle, vertical	160 °
Display number of colors	16.78 million colors
Viewable size, horizontal	442.8 mm
Viewing angle, horizontal	170 °
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1600 x 900
DVI-I ports quantity	0
Product color	Black
Market positioning	Business
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Panel mounting interface	100 x 100 mm
Input current	1.6 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	26 W
Sustainability certificates	EPEAT Gold, ENERGY STAR
Package weight	6350 g

Weight and Dimensions

Depth (with stand)	151.9 mm
Width (with stand)	481.2 mm
Height (with stand)	363.2 mm
Weight (with stand)	4850 g
Weight (without stand)	3500 g
